EshaPlan MF System on Timber/Concrete Deck

Description

Reinforced, PVC-P waterproofing membranes for single-ply roofs.

General information

Material

Bitumen

Uniclass 2015

Pr_25_57_51_66 Polymeric membranesPrimary

Specification data - Polymeric membranes

Product Reference

EshaPlan B

Glass-fibre reinforced, adhered applications.

EshaPlan FM

Glass fibre reinforced, fleece backed, adhered applications.

EshaPlan MF

Polyester reinforced, mechanical or adhered applications.

Thickness

1.2 mm

EshaPlan B and EshaPlan MF only.

1.5 mm

EshaPlan FM only.

1.8 mm

EshaPlan FM only.

1.95 mm

EshaPlan B and EshaPlan MF only.

2.0 mm

EshaPlan FM only.

2.34 mm

EshaPlan B and EshaPlan MF only.

2.65 mm

EshaPlan B and EshaPlan MF only.

Width

1.06 m

EshaPlan B and EshaPlan MF only.

1.50 m

EshaPlan B and EshaPlan MF only.

2.12 m

Colour

Anthracite, RAL 7015

Blue, RAL 5005

EshaPlan B and EshaPlan MF only.

Green, RAL 6004

EshaPlan B and EshaPlan MF only.

Light grey, RAL 7001

Stone red, RAL 3011

EshaPlan B and EshaPlan MF only.

Turquoise, RAL 5018

EshaPlan B and EshaPlan MF only.

White, RAL 9010

EshaPlan B and EshaPlan MF only.

Standard product features

Recycled materials:

Membranes contain approximately 5% recycled materials.

Product Options

Product reference:

– EshaPlan B:

  • Visible defects (EN 1850-2): Pass.
  • Length (EN 1848-2): 15 or 20 m -0/+5%.
  • Width (EN 1848-2): 1.06, 1.50 or 2.12 m -0.5/+1%.
  • Straightness (EN 1848-2): ≤30 mm.
  • Flatness (EN 1848-2): ≤10 mm.
  • Mass per unit area (EN 1849-2): 1.95, 2.34 and 2.65 kg/m² -5/+10%.
  • Effective thickness (EN 1849-2): 1.2, 1.5, 1.8 or 2.0 mm -5/+10%.
  • External fire performance (ENV 1187 and EN 13501-5): Froof.
  • Reaction to fire (EN 13501-1): Class E.
  • Water tightness (EN 1928-B): Pass.
  • Tensile strength (EN 12311-2-A): ≥7 N/mm².
  • Elongation (EN 12311-2-A): ≥ 100%.
  • Root resistance (prEN 13948): NPD.
  • Resistance to static load (EN 12730 A and B): ≥20 kg.
  • Resistance to impact: (EN 12691 A and B): ≥500 mm.
  • Tear resistance (EN 12310-2): ≥125 N.
  • Joint peel resistance (EN 12316-2): ≥ 185 N/50 mm.
  • Joint shear resistance (EN 12317-2): ≥ 700 N/50 mm.
  • Durability UV heat and water (EN 1297 5000 hrs): Pass.
  • Foldability at low temperature (EN 495-5): ≤-25 ºC.
  • Dimensional stability (EN 1107-2): ≤0.5%.
  • Hail resistance (EN 13583): ≥ 17 m/s.
  • Water vapour resistance, µ (EN 1931): 20 ±30%.

– EshaPlan FM:

  • Visible defects (EN 1850-2): Pass.
  • Length (EN 1848-2): 15 or 20 m -0/+5%.
  • Width (EN 1848-2): 2.12 m -0.5/+1%.
  • Straightness (EN 1848-2): ≤30 mm.
  • Flatness (EN 1848-2): ≤10 mm.
  • Mass per unit area excluding fleece (EN 1849-2): 1.95, 2.34 and 2.65 kg/m² -5/+10%.
  • Effective thickness (EN 1849-2): 1.5, 1.8 and 2.0 mm -5/+10%.
  • External fire performance (ENV 1187 and EN 13501-5): Froof.
  • Reaction to fire (EN 13501-1): Class E.
  • Water tightness (EN 1928-B): Pass.
  • Tensile strength (EN 12311-2-A): ≥600 N/50 mm.
  • Elongation (EN 12311-2-A): ≥30%.
  • Root resistance (prEN 13948): NPD.
  • Resistance to static load (EN 12730 A and B): ≥20 kg.
  • Resistance to impact: (EN 12691 A and B): ≥500 mm.
  • Tear resistance (EN 12310-2): ≥200 N.
  • Joint peel resistance (EN 12316-2): ≥ 185 N/50 mm.
  • Joint shear resistance (EN 12317-2): ≥ 600 N/50 mm.
  • Durability UV heat and water (EN 1297 5000 hrs): Pass.
  • Foldability at low temperature (EN 495-5): ≤-25 ºC.
  • Dimensional stability (EN 1107-2): ≤ 0.3%.
  • Hail resistance (EN 13583): ≥ 17 m/s.
  • Water vapour resistance, µ (EN 1931): 20 ±30%.

– EshaPlan MF:

  • Visible defects (EN 1850-2): Pass.
  • Length (EN 1848-2): 15 or 20 m -0/+5%.
  • Width (EN 1848-2): 1.06, 1.50 and 2.12 m -0.5/+1%.
  • Straightness (EN 1848-2): ≤30 mm.
  • Flatness (EN 1848-2): ≤10 mm.
  • Mass per unit area (EN 1849-2): 1.95, 2.34 and 2.65 kg/m² -5/+10%.
  • Effective thickness (EN 1849-2): 1.2, 1.5, 1.8 and 2.0 mm -5/+10%.
  • External fire performance (ENV 1187 and EN 13501-5): Broof t1.
  • Reaction to fire (EN 13501-1): Class E.
  • Water tightness (EN 1928-B): Pass.
  • Tensile strength (EN 12311-2-A): MD, ≥1000 N/50 mm; CD, ≥ 900 N/50 mm.
  • Elongation (EN 12311-2-A): ≥ 15%.
  • Root resistance (prEN 13948): NPD.
  • Resistance to static load (EN 12730 A and B): ≥20 kg.
  • Resistance to impact: (EN 12691 A and B): ≥500 mm.
  • Tear resistance (EN 12310-2): ≥200 N.
  • Joint peel resistance (EN 12316-2): ≥ 185 N/50 mm.
  • Joint shear resistance (EN 12317-2): ≥ 700 N/50 mm.
  • Durability UV heat and water (EN 1297 5000 hrs): Pass.
  • Foldability at low temperature (EN 495-5): ≤-25 ºC.
  • Dimensional stability (EN 1107-2): ≤0.5%.
  • Hail resistance (EN 13583): ≥ 17 m/s.
  • Water vapour resistance, µ (EN 1931): 20 ±30%.

Digital objects

Platform Compatible Version Certified to
IFC

IFC2X3

1

 1.3
Revit

Revit 2016

3

 2.0
Download now from NBS National BIM Library

Literature

Roofing Systems Brochure

Roofing Systems Brochure

Third party certifications

  • CE marked: Certificate: 1213-CPR-066 : Tested to EN 13956
