EQUITONE [pictura] - Fibre Cement Rainscreen Cladding

Name: EQUITONE [pictura] - Fibre Cement Rainscreen Cladding
Brand: EQUITONE
SKU: b4GY3uBWmgMdvrj3PuTb4A

Verified by manufacturer 2 months ago

Matt Black PA041

EQUITONE

Third party certifications:

DoP
Certificate type
BBA Agrément Certificate
Certificate type
Cradle to Cradle Certified
Certificate type
EPD
Certificate type

EQUITONE [pictura] is a fibre cement rainscreen cladding material with a UV cured top layer, which offers a selection of colour coatings in a smooth and ultra matt finish.

Jump to:

BOS

+44 (0)1283 501 555 Website

Application

Suitable for a ventilated rainscreen cladding / facade system.

Description

EQUITONE [pictura] is a high density, fibre cement cladding panel suitable for use as part of a decorative rainscreen facade system. The UV cured top layer of the panel is smooth and easily cleanable , acting as an anti-graffiti coating.

Features and benefits:

Fire Classification A2-s1,d0.
BBA approved.
Sound insulating.
Resistant to extreme temperatures and frost.
Water resistant (if in compliance with application guideline).
Resistant to many living organisms (fungi, bacteria, insects, vermin, etc).
Resistant to many chemicals.
Environmentally friendly, no harmful gas emissions.
Material appearance due to transparent coating.
Strong, rigid fibre cement panels.
EPD available.

General information

Color	Beige Black Blue Brown Cream Green Grey Orange Purple Red Yellow White Other Show more Manufacturer guidance Available in 20 colours.
Finish	Matt Manufacturer guidance EQUITONE [Pictura] has a smooth, matt finish with no visible fibres.
Material	Fibre cement Manufacturer guidance Fibre cement - made of water, Portland cement, cellulose and natural minerals.
Shape	Rectangle Manufacturer guidance Can be easily cut into many shapes and sizes.
Length	2500 mm 3100 mm
Width	1250 mm

Uniclass	Pr_25_71_11_25 Fibre-reinforced cement boardsPrimary Ss_25_20_70_25 Drained and back-ventilated rainscreen cladding systems Ss_25_20_70_65 Pressure equalized rainscreen cladding systems Ss_25_20_15_16 Concrete panel cladding systems
CAWS	H30/120 Fibre cement H30/110 Fibre cement H20/10 Sheet cladding H20/155 Sheet cladding (attached to timber battens) H92/120 Rainscreen cladding H20/150 Sheet cladding (attached to metal support systems)

Specification data - Fibre-reinforced cement boards

Standard	To EN 12467, EN 15804.
Fire rating	To EN 13501-1, A2-s1,d0.
Weather resistance	To BS EN 12467, category A. Manufacturer guidance Resistant to extreme temperatures, frost, and is water resistant (if in compliance with application guidelines).
Bending strength	To BS EN 12467, Class 4.
Sheet size	-
Nominal thickness	8 mm. 12 mm.
Length	2500 mm. 3100 mm.
Width	1250 mm.
Edges	Open joints. Fitted with a decorative trim profile.
Colour	Matt Black PA041.
Execution	- Manufacturer guidance Face Fix with either Rivet or Screw and Mechanical Secret Fix (MSF). EQUITONE panels are installed to the ventilated rain screen principle, allowing air to flow in through the base and out at the top with a minimum 30 mm ventilation gap from the back of the panel to the structure/ insulation. EQUITONE is installed with 8–12 mm open joints and can be installed onto timber battens or a metal framing system in a range of designs. It is recommended that you consult the manufacturer's literature or technical team for further installation information.

Surface texture	Smooth. Guidance for specification option: EQUITONE [natura] has a tactile, smooth surface that allows the textures of the fibre cement to show through.
Joint size	8–12 mm.
Durability classification	To EN 12467, Category A.
Apparent density	To EN 12467, 1650 kg/m³.
BendingStrength	To BS EN 12467, 24 N/mm² (perpendicular); 18 N/mm² (parallel).
WaterImpermeability	To EN 12467, pass.
Freeze-thaw resistance	To EN 12467, pass. Manufacturer guidance Freeze Thaw Test Category A Panel.
Movement	0.01 mm/Mk. Manufacturer guidance Thermal movement.
ThermalConductivity	0.6 W/Mk.

Sustainability data

Country of product manufacture	Germany
Material	Fibre cement Manufacturer guidance Fibre cement - made of water, Portland cement, cellulose and natural minerals.
Embodied carbon A1-A3 (production stage) as defined in BS EN 15804	1.86 kg CO₂ eq/m²
Recyclability	- Manufacturer guidance With an expected lifetime of 50 years or more, EQUITONE panels often outlast the building lifetime. They are designed for disassembly with reversible fixation systems, allowing reuse in facade cladding or other applications. All EQUITONE waste generated in the production phase is recycled in material loops, such as transportation to the cement kiln, where it is reactivated.
