EOS97 Walk On Flat Glass Rooflight - Single Pane - Rooflight
Verified by manufacturer 1 day ago
EOS97 Walk On Flat Glass Rooflight - Double Glazed (With upstand)
EOS97 Walk On Flat Glass Rooflight - Double Glazed (With upstand)
Robust and insulated fixed walk-on glass rooflight.
Application
Residential and commercial flat roof and balcony applications that require pedestrian traffic.
Description
Robust and insulated fixed walk-on glass rooflight.
Features and benefits:
- Maximizes outdoor space, and is designed to sit flush on the chosen surface.
- Available with a range of anti-slip finishes.
- Can withstand 2500 N/m² uniform load.
- Manufactured to meet the requirements of EN 14351-1.
- Made-to-measure sizes available.
- Double and triple glazing available.
- The glass surface is raised above the frame edge to allow water run-off. Glass surface edges have been painted with a ceramic paint to protect against UV degradation.
- Complete unit (glass, frame and kerb) can be supplied to a CWCT TN66/67, Class 0 specification for impact resistance to reduce the likelihood of death or injury caused by falls.
- Designed for quick and simple installation by any roofing/ main contractor.
- Part L compliant upstand.
- Weathertightness tested to BS 6375-1.
- Air permeability tested to BS EN 1026.
- Watertightness tested to BS EN 1027. Class R7.
- Wind resistance tested to BS EN 12211. Class E2400 Pa.
- Airtight to CWCT Class A4 air leakage.
- Sound reduction tested to EN ISO 717-1, 34 dB (-2, -6).
General information
Color | Grey Guidance for specification option: Frame. Clear Guidance for specification option: Glazing. Other |
Finish | Powder-coated Matt Anti-slip |
Material | Aluminium Glass |
Shape | Square Rectangle Other |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke Guidance for specification option: Dependent on glazing configuration and upstand size. |
Warranty description | Ten year |
Uniclass | |
CAWS | L10/460 Rooflights L10/45 Rooflights |
Specification data - Framed rooflights
Classification data | |
Form | Flat. |
Size | Manufacturer guidance
Consult manufacturer and insert requirements. |
Product performance | |
Whole window U-value | 0.96 W/m²K. Guidance for specification option: Achieves system U values as low as 0.96 W/m²K (dependent on glazing and upstand types). Consult manufacturer for details. |
Frame | |
Material | Aluminium. |
Finish | |
Coating | Powder coating. |
Colour | RAL 7016, anthracite grey. Guidance for specification option: 30% gloss. Other. Guidance for specification option: A wide choice of RAL frame colours available. Consult manufacturer for details. |
Glazing or infill | |
Type | Insulating glass units. Other. Guidance for specification option: Other glass specifications are available on request, including laminated safety glass. Consult manufacturer and insert requirements. |
Construction | Double skin. Guidance for specification option: Double glazed specification: 52 mm double glazed low emissivity insulating glass units, 33 mm laminated outer pane, 14 mm argon filled cavity and 6 mm toughened super Low E inner pane. Other configurations available. Consult manufacturer for details. |
Colour | Clear. |
Coating | Not required. Anti-slip. Guidance for specification option: Nine options available, consult manufacturer and insert requirements. |
Integral kerb | Aluminium. Guidance for specification option: Supplied unfinished. |
Operation | |
Type | N/A - fixed pane. |
Control | N/A - fixed pane. |
Accessories | Not required. Black banding. Guidance for specification option: Add a sleek aesthetic with a black vinyl paint border applied before glazing. This feature creates a seamless finish when viewed from above, ensuring a clean and modern look from every angle. |
Upstand | Insulated upstand. Guidance for specification option:
Consult manufacturer for details and insert requirements. Manufacturer guidanceFully insulated timber upstand with warm core foam insulation. |
Design | Internal walk-on. External walk-on. |
Sustainability data
Country of product manufacture | United Kingdom |
Material | Aluminium Glass |
