Application

For restaurants, retail and leisure, office, healthcare, education and residential applications.

Description

ELEGANZA™ Seamless Acoustics offers a 100% seamless finish featuring a durable finely textured visual that stays whiter and brighter for longer.


Features and benefits:

  • 100% seamless – the absence of visible joints provides a long-lasting durable finish and a monolithic appearance.
  • Class A sound absorption for improved acoustic comfort performances (0.95 aw).
  • Durable surface thanks to an airtight system and a finely textured surface.
  • Full-system solution from a unique supplier for a reassuring system guarantee.
  • Large panels and few joints making it easy and fast to install.
  • Complete solution compatible with standard accessories.
  • Indoor Air Comfort GOLD certified product.
  • Indoor Air Quality A+.

General information

Color

White

Other

Guidance for specification option:

RAL colours available on request.

Finish

Textured

Shape

Rectangle

Length

2400 mm

Width

1200 mm

Height

25 mm

Warranty description

-

Manufacturer guidance

Please refer to manufacturers guidelines

Uniclass

Ss_30_25_10_10 Board suspended ceiling systemsPrimary

CAWS

K40/20 Board-suspended ceiling systems

K40/135 Board-suspended ceiling system

Specification data - Board suspended ceiling systems

Suspension grid

Rapid’Fix Grid System.

Guidance for specification option:

  • Rapid’Fix Unhemmed C-Channel.
  • Rapid’Fix Main Runner.
  • Rapid’Fix Cross Tee.
  • Nonius Bottom for T-Bar (40 kg) or Short Nonius Hanger (upper & lower part) or Hanger M6 Threaded Rod.
  • Drywall Adapter Clip/ DB 3 T-Connector.
  • DGSC180 Connector 180°/ DGTC90 Connector 90°.

Suspension grid fasteners

-

Manufacturer guidance

Insert requirements.

Linings

-

Face layer

Eleganza Panels.

Guidance for specification option:

2400 x 1200 x 25 mm ( L x W x H).

Fasteners

Eleganza Fixing Ring and drywall screws.

Joint treatment

Panels: Eleganza Airtight Tape and Eleganza Acoustic Joint Filler; Ceiling/ wall junction: Knauf Fix & Finish Maleracryl.

System accessories

None.

Access panels (specified seperately).

Guidance for specification option:

  • A standard inspection hatch designed for 25 mm plasterboard may be used. Always refer to the guidelines of the inspection hatch manufacturer.
  • To create additional support, Rapid’Fix Cross Tees can be used to create a frame for inspection hatches. For further information, please see the Eleganza Seamless Acoustic Installation Guide.
  • The surface of the inspection hatch may also be sprayed with Eleganza Silent Plaster to create a homogeneous appearance.

Expansion joints.

Guidance for specification option:

  • Insert requirements.
  • Where expansion joints are necessary, the appropriate stock expansion joint profiles for 25 mm plasterboard can be used.
  • Please take national regulations and standards into account.
  • For more information, refer to the guideline for Seamless Acoustic Ceilings (available on request by Knauf Ceiling Solutions).

Execution

-

Manufacturer guidance

Refer to the ELEGANZA Seamless Acoustics Installation Guide.

Surface finish

Eleganza Silent Plaster Acoustic Finish.

Sound absorption

Class A measured in accordance with EN ISO 354 and rated in accordance with EN ISO 11654.

Sound attenuation

Dn,f,w = 33 dB tested in accordance with EN ISO 10848-2 and rated in accordance with EN ISO 717-1.

Sound reduction

Rw = 18 dB measured in accordance with EN ISO 10140-2 and rated in accordance with EN ISO 717-1.

Reaction to fire

To EN 13501-1, Euroclass A2-s1, d0.

Sustainability data

Contains Red List materials

-

Manufacturer guidance

Please refer to manufacturers guidelines

Country of material origin

Germany

Manufacturer guidance

Please refer to manufacturers guidelines

Country of product manufacture

Germany

Embodied carbon

A1-A3 (production stage) as defined in BS EN 15804

-

Manufacturer guidance

Please refer to manufacturers guidelines

Recyclability

-

Manufacturer guidance

Please refer to manufacturers guidelines

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

21 %

Literature

TBA Guideline 3.7 Seamless Acoustic Ceilings

TBA Guideline 3.7 Seamless Acoustic Ceilings

ELEGANZA Seamless Acoustics Installation Guide

ELEGANZA Seamless Acoustics Installation Guide

ELEGANZA Seamless Acoustics Data Sheet

ELEGANZA Seamless Acoustics Data Sheet
