Elegance 52 Curtain Walling
Aluminium curtain walling.
Aluminium curtain walling in a choice of appearances.
Features:
- Accommodates other window and door systems.
- Additional aluminium or steel profiles can be inserted into mullions for large spans.
- Can form vertical, sloped or roof glazing, incorporating fixed and opening lights and doors.
- Dual colour available; differing finishes internally and externally possible.
- Drained and ventilated glazing, 4–50 mm thick; EPDM gaskets.
- Continuous PVC thermal breaks.
- Size (maximum) as manufacturer's table.
Standards:
CWCT and EN 13830 Taylor Woodrow Technology.
Size | Insert requirements. |
Finish | Anodized To BS 3987. Powder coated gloss, colour To EN 12206-1: 2004, insert colour. Powder coated matt, colour To EN 12206-1: 2004, insert colour. Powder coated metallic, colour To EN 12206-1: 2004, insert colour. Powder coated satin, colour To EN 12206-1: 2004, insert colour. |
Features | Accommodates other window and door systems Additional aluminium or steel profiles can be inserted into mullions for large spans Can form vertical, sloped or roof glazing, incorporating fixed and opening lights and doors Dual colour available; differing finishes internally and externally possible Drained and ventilated glazing, 4–50 mm thick; EPDM gaskets Continuous PVC thermal breaks Size (maximum) as manufacturer's table |
Uniclass 2015 |
Product Reference | Elegance 52 Curtain WallingOn site, stick construction. |
Type (Elegance 52) | GFCassette glazing. HLFrame horizontally capped. SGStructural glazing, carrier frame. SGVStructural glazed vent. STFull capped. SXStructural glazing, toggle. |
Size | Insert requirements. |
Finish | AnodizedTo BS 3987. Powder coated gloss, colourTo EN 12206-1: 2004, insert colour. Powder coated matt, colourTo EN 12206-1: 2004, insert colour. Powder coated metallic, colourTo EN 12206-1: 2004, insert colour. Powder coated satin, colourTo EN 12206-1: 2004, insert colour. |
Glazing | 24 mm28 mm32 mm |
Accessories | NoneAero Clip sun screeningEco Clip sun screeningSide-arm sun screeningPhotovoltaic panels |
Product Options | Product reference: Windows and doors may also be specified as part of curtain walling system. Glazing: 24, 28 or 32 mm as standard. Insert details of glass and spacer dimensions, emissivity, safety and solar control. |
