Ecoscape UK Forma® Panel Cladding
Verified by manufacturer over a year ago
Composite panel cladding.
Application
Cladding applications.
Description
Forma panel cladding is a long lasting, low maintenance alternative to timber that can be used on various exterior projects; from home renovations to new build apartments, sunrooms or contemporary garden rooms. This stunning material from the capped Forma® range looks as impressive as natural wood cladding with no need to paint, stain or oil. Forma cladding products come with a 25 year warranty.
This 95% recycled board brings all of the benefits of a synthetic product without any of the negative plastic associated drawbacks.
Features and benefits:
- 25 year warranty.
- Low maintenance.
- Fast, easy installation.
- UV-stable.
- Hidden fixings.
- FSC certified, and manufactured in accordance with ISO 9001, ISO 14001.
Ecoscape UK composite cladding boards must be supported by a substructure placed at 500 mm centers.
General information
Color | Grey Brown |
Finish | Brushed |
Material | Composite |
Shape | Rectangle |
Length | 3600 mm |
Width | 142 mm |
Height | 13 mm |
Warranty description | 25 year |
Uniclass | |
CAWS | H22/10 Plastics weatherboarding H22/110 Plastics weatherboarding |
Specification data - Wood-plastics composite weatherboards
Profile | Shiplap. |
Finished size | |
Face width | 142 mm ( 132 mm installed). |
Thickness | 13 mm. |
Surface texture | Smooth. |
Finish | Brushed. |
Reaction to fire classification | To EN 13501-1, D-s1, d0. |
Colour | Argent.Flint.Havana.Midnight.Silver Birch.Spiced Oak. |
Recycled content (minimum) | 95%. |
Trim | Angle trim. End trim. External corner trim. Finishing trim. Internal corner trim. |
Board | 3600 x 142 x 13 mm cladding board. |
Flexural strength | To EN 15534, Average Bending Strength: 31.9 MPa. Modulus of Elasticity in bending: 3993 MPa. Deflection at 250 N: Mean: 1.93 mm, 2.02 mm maximum. |
Linear thermal expansion coefficient | To EN EN 15534, Longitudinal direction: 46.0 ×10-6 K-1. |
Sustainability data
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 95 % |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 1 |
 Revit | - | 1 |
Literature
ECO3600XX-001 3600 x 142 x 13mm Forma Panel Cladding Board Product Detail
Ecoscape UK Panel Cladding Installation Guide
Ecoscape UK Panel Cladding Technical Specification
