Ecoscape UK Clarity® Decking

Verified by manufacturer 6 months ago

Ecoscape UK

Composite decking system.

Jump to:
BOS
+44 (0)845 9011988 Website

Application

External decking.

Description

The Clarity range is an entry level, high quality decking system. It is 95% recycled, and doesn’t need to be painted, stained or sealed. Each board is reversible, with one side displaying narrow grooves and the other wider grooves, allowing designs to be more interesting. The Clarity decking boards are available in five different colours each inspired by real wood.


Clarity composite decking is a beautiful low maintenance alternative to timber. This 95% recycled board brings all of the benefits of a synthetic product without any of the negative plastic associated drawbacks. The unique contemporary grooved finish generates clean lines and is the perfect accompaniment to any outdoor project. The purposefully designed surface texture of the boards generate an exceptional anti-slip rating making it an ideal surface for those with a safety conscious mind.


Features and benefits:

  • 20 year warranty.
  • Low maintenance.
  • Slip resistant.
  • Fast, easy installation.
  • The boards far exceed the required PTV slip resistance value of 36 required to be classified as low slip potential (wet and dry conditions).
  • Hidden fixings.
  • FSC certified, and manufactured in accordance with ISO 9001, ISO 14001.

General information

Color

Grey

Brown

Finish

Matt

Material

Composite

Shape

Rectangle

Length

3000 mm

4800 mm

Width

150 mm

Height

25 mm

Warranty description

20 year

Uniclass

Ss_30_20_30_25 Decking systemsPrimary
Pr_25_71_97_94 Wood-plastics composite deck boards

CAWS

Q55/110 Deck

Specification data - Decking systems

Structure

-

Subframe

Ecoscape UK Plastic Joist Substructure.

Guidance for specification option:

  • 100 x 100mm Post
  • Concrete Post Foundation
  • Framing Joist (125 x 50mm Plastic Joist
  • Joist - 125 x 50mm Plastic Joist
  • Noggin - at 1500 mm maximum centres along joist.

Deck boards

-

Material

Wood-plastics composite deck boards

Fasteners

Hidden T-Clip.

Locking Clip.

Start/ Finish Clip.

System accessories

Angle trim.

3000 x 150 x 10 mm Forma Flat Trim.

Board

4800 x 150 x 25 mm Clarity Deck Board.

3000 x 150 x 25 mm Clarity Deck Board.

2900 x 150 x 25 mm Solid Edge Board (Narrow).

2900 x 150 x 25 mm Solid Edge Board (Wide).

3000 x 150 x 25 mm Solid Edge Board (Narrow).

Show more

Colour:

Ash.

Autumn.

Charcoal.

Graphite.

Walnut.

Deck board finish

1/4” (6 mm) Groove.

1” (25 mm) Groove.

Abrasion resistance

To ASTM D4060-10, 33 mg (1000 cycles).

Bond strength

To EN 319, Average Bond Strength > 2.3 MPa.

Co-efficient of linear thermal expansion

To EN 15534, 34.7x10-6K-1.

Fire resistance

To EN 13501, Cfl-S1.

Formaldehyde emissions

To EN717/ ASTM D6007-14, Non Detected.

Flexural strength

To EN 15534, Bending Strength: 26.93 MPa. MOE: 4.26 GPa. Max Load: 4029 N. Deflection at 500 N: 0.57 mm.

Impact resistance

To EN 15534, MFE>396 J.

MoistureContent

To EN 15534/ EN 322, 0.56%.

Scratch resistance

To ISO4586-2, Resistance to Scratch Rate 2.

Thermal resistance

Thermal Conductivity: To EN 14041, 03589W/(m-K). Thermal Resistance: To ASTM C518-2010, 0.0830(m²-K)/W.

Slip resistance

To EN 15534:
Dry Conditions: Wide Groove: 61(L)/88(W), Narrow Groove: 66(L)/99(W).
Wet Conditions: Wide Groove: 45(L)/48(W), Narrow Groove: 47(L)/53(W).

Sustainability data

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

95 %

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1
