Easy Glass® SMART

Q-railing Variant:

Glass balustrade designed for quick installation and with adjustable panel alignment.

Jump to:
+44 (0)1782 711676 www.q-railing.com

Application

For light to medium indoor or outdoor use in stairs and balustrades.

Description

Glass balustrade designed for quick installation and with adjustable panel alignment.


Features and benefits:

  • Uses the adjustable Q-disc System, which simplifies and speeds up the installation and glass infill alignment of individual glass panels by up to 0.6° from the vertical. Q-disc has been awarded the prestigious Red Dot Design Award.
  • The Q-disc system is also suitable for mounting on uneven floors.
  • Suitable for glass 12–21.52 mm thick (fixed) or 12–17.52 mm thick (adjustable). For thicker glass requirements (16.76–25.52 mm), use Easy Glass® PRIME (specified separately).
  • Top-mounted (symmetrical or F-shaped) or fascia-mounted (symmetrical or Y-shaped).
  • Minimal use of anchors in base shoe installation.
  • A choice of base shoe fixing methods (hexagon bolts, mechanical anchors or stud anchors and cost-effective alternatives).
  • Optional cladding and shoe shims for levelling uneven surfaces.
  • Glass balustrade trims are available for various mounting situations.
  • Compatible with all Q-railing glass-mounted handrails, cap rails, U-profiles and edge.
  • Can be combined with the Q-lights range: handrails with spotlights (Q-lights Spotlight), and handrails or cap rails with linear LED strips (Q-lights Linear Light).
  • Consult manufacturer for certificate details; detailed testing reports and calculations available on request.

General information

Color

Silver

Aluminium.

Finish

Brushed

Aluminium only.

Mill

Aluminium only.

Material

Aluminium

Glass

Rubber

Size

115 x 127 mm

200 x 66 mm

Uniclass 2015

Ss_25_60_05_05 Balustrade and guarding systemsPrimary

CAWS

L30/55 Proprietary balustrades

L30/560 Proprietary balustrades

Specification data - Balustrade and guarding systems Enhanced data

Infills

Glass, 12–21.52 mm.

Fixed Q-disc system.

Insert glass type and thickness required to ensure appropriate seals are specified.

Rails

-

Handrails

Cap rail (continuous).

Consult manufacturer's literature for options and insert requirements.

Glass-mounted handrail.

Consult manufacturer's literature for options and insert requirements.

Glass-mounted handrail with Q-lights Spotlight.

LED-lit handrail (spotlights), specified separately.

Glass-mounted handrail with Q-light Linear Light.

LED-lit handrail (LED linear strips), specified separately.

U-profiles.

Consult manufacturer's literature for options and insert requirements.

Edge protection.

Consult manufacturer's literature for options and insert requirements.

Other.

Consult manufacturer's literature for options and insert requirements.

Not required.

Base rails

Standard base shoe, brushed anodized finish.

MOD.6930

Minimum edge distance to anchor (horizontal) applies; consult manufacturer's literature for details.

Profile: 115 x 60 mm.

Standard base shoe, mill finish.

MOD.6930

Minimum edge distance to anchor (horizontal) applies; consult manufacturer's literature for details.

Profile: 115 x 60 mm.

F-shaped base shoe; brushed anodized finish.

MOD.6932

For unfinished floors and for installing at or beyond the edge of a surface.

Minimum edge distance to anchor (horizontal) applies; consult manufacturer's literature for details.

Profile (main shoe section only): 115 x 60 mm.

F-shaped base shoe; mill finish.

MOD.6932

For unfinished floors and for installing at or beyond the edge of a surface.

Minimum edge distance to anchor (horizontal) applies; consult manufacturer's literature for details.

Profile (main shoe section only): 115 x 60 mm.

Fixing to parent structure

A choice of base shoe fixing methods are available (hexagon bolts, mechanical anchors or stud anchors and cost-effective alternatives); consult manufacturer for options and insert requirements.

Samples required

Product samples.

Prototypes or mock-ups.

Standards

To BS 6180.

Third party accreditation

AbP certification, test certificate number P-2018-3018; UNI EN 11678 approved; CTE-tested.

Detailed testing reports and calculations available on request.

CTE: Código Técnico de la Edificación.

Accessories

None.

Easy Glass trims.

Creates a seamless connection between a balustrade’s base channel and adjacent floor or cladding.

There are Easy Glass trims available for various mounting situations, consult manufacturer for details..


The trim rubbers help to hold the profiles in place during installation; they can also can be used as spacers between the glass panels.

Additional handrails.

Insert requirements or specify separately.

Additional handrails, Q-lights Spotlight.

LED-lit handrail (spotlights), specified separately.

Additional handrails with Q-light Linear Light.

LED-lit handrail (LD linear strips), specified separately.

Show more

Dimensions

115 x 127 mm

Digital objects

Platform Compatible Version Certified to
Revit
-

1

2.1
IFC
-

1

2.1
Download now from NBS National BIM Library

Literature

BS 6180 Smart Test Data

BS 6180 Smart Test Data

Easy Glass SMART

Easy Glass SMART

Systems Brochure

Systems Brochure
