Drawn Lines - LVT
Description

A 4.5 mm thick high-performance luxury vinyl tile in a skinny plank format. It has a never-ending geometric pattern design with a soft pooling of light and dark areas and no visible repeats.

Drawn Lines is compatible for use with a modular carpet. Both hard and soft tiles are fully compatible in size and height, so they can sit side by side with no need for transition strips, connectors or bridges. The Ceramor™ UV-stabilized ceramic bead top layer delivers great longevity, and the Sound Choice™ backing layer dampens impact sound.

Features:

  • Available in ten colourways from warm to cool.
  • Émissions dans l'air intérieur A+ rating.
  • Compliant with AgBB LEED EQ 4.3 credit.
  • CE marked to BS EN 14041.
  • Compatible with TacTiles™ glue-free installation system - up to 50 m².

General information

Features

Available in ten colourways from warm to cool

Émissions dans l'air intérieur A+ rating

Compliant with AgBB LEED EQ 4.3 credit

CE marked to BS EN 14041

Compatible with TacTiles™ glue-free installation system - up to 50 m²

Finish

Ceramor™ - UV-stabilized ceramic bead coating

Size

250 x 1000 mm

Uniclass 2015

Pr_35_57_71/432 PVC and resilient laminate strips and tilesPrimary

CAWS

M50/10 Resilient floor tiling

M50/110 Resilient floor tiling

Specification data - PVC and resilient laminate strips and tiles

Product Reference

Drawn Lines - LVT

Colour

A00902 Topaz

A00903 Bronze

A00904 Smokey quartz

A00905 Amber

A00906 Aquamarine

A00907 Onyx

A00908 Silver

A00909 Diamond

A00910 Opal

A00911 Amethyst

Standard product features

Type:

High-performance luxury vinyl tile.

Finish:

Ceramor™ - UV-stabilized ceramic bead coating.

Size:

250 x 1000 mm.

Thickness:

Wear layer: 0.55 mm.

Total: 4.5 mm.

Weight:

6700 g/m².

Backing:

Sound Choice™ acoustic backing.

Method of laying:

Ashlar or herringbone.

Technical properties:

  • Wear classification (to BS EN ISO 1307): Class 33 Heavy Commercial/ Class 42 General Light Industrial.
  • Radiant panel (to BS EN 13501): Euroclass Bfl-s1.
  • Dimensional stability (to ISO 23999): ≤0.25%.
  • Curling (to ISO 23999): ≤2 mm.
  • Flexibility (to BS EN ISO 24344): Method A - Pass.
  • Abrasion resistance (to BS EN 660-2): Group T.
  • Residual indentation (to BS EN ISO 24343-1): ≤0.2 mm.
  • Determination of anti-slip (to DIN 51130): R10.
  • Chemical resistance (to BS EN ISO 26987): Very good.
  • Impact sound insulation ΔLw (to BS EN ISO 10140-3): 16 dB.
  • Slip resistance (to BS EN 14041): Class DS.
  • Formaldehyde rating (to BS EN 14041): E1.
  • Anti-static (to BS EN 14041): 0.2 kV.
  • Colour fastness - Light (to ISO 105/B02): ≥7.
