DNSB-A

Description

DNSB-A is a low frequency wall tie. This sway brace has a bolt end for stud walls or hooked end for masonry walls. It is important that the walls of a space sensitive to noise or vibration transmission are isolated from the main building structure.

These acoustically isolated walls can be built on a floating floor or specially designed wall support plates. If the wall requires lateral support, DNSB-A anti-vibration wall braces will be required. These sway braces are available with various ends to suit different wall constructions. DNSB-A acoustic sway braces are supplied pre-compressed to ensure consistent acoustic isolation while tolerating a range of wall loads.

General information

Features

Bolt end for stud walls or hooked end for masonry walls

Material

Steel, rubber

Size

121 x 105 x 51 mm

Digital objects

Platform Compatible Version Certified to
Revit
-

1

2.1
IFC
-

1

2.1
Download now from NBS National BIM Library
