Description

Dimi acoustic sheet material with an almost invisible perforation pattern; both products classic and finest are specially developed for contractors and installers. The panels can be manufactured to order up to a maximum length of 3500 mm and in any laminate finishes, real wood veneers or painted/ lacquered finishes. Other formats cut to dimension and edge banding is available. The panels are produced in a symmetrical structure and thus are ideally suited for use in furniture manufacturing. They have low torsion and resistance ability against mechanical stress.

General information
Finish

Insert requirements from 'Options' below.

Uniclass 2015 Acoustic duct linings (Pr_65_67_78_02)
Specification data
Product Reference

Dimi Classic

3000 x 3000 x 1.5 mm.

Dimi Finest

1800 x 1800 x 0.5 mm.

Core board

Chipboard

Gypsum fibre

MDF

Finish

Insert requirements from 'Options' below.

Standard product features

Sheet size:

2800 x 1320 mm.

Total thickness:

20 mm.

Fire Classification EN 13501-1:

  • B-s1,d0: Engineered real wood veneer, lacquer finish.
  • B - s2, d0: CPL.

Formaldehyde:

E1 in composite (WKI certified).

Open surface:

  • Classic: 8.7%.
  • Finest: 6.1%.

Holes:

  • Classic: 111/ m².
  • Finest: 309/ m².

Product Options

Sound absorption values:

Consult manufacturer's literature for details.

Finish:

- Real wood veneers:

  • Canadian Maple.
  • European Oak.
  • American Walnut.

- CPL/ melamine:

  • W980 ST2/ ST15 Platinum White.
  • W1000 ST9 Premium White.
  • U999 ST2 Black.
  • F509 ST2 Aluminium.
  • U156 ST9 Sand Beige.
  • U708 ST15 Light Grey.
  • H1277 ST9 Light Lakeland Acacia.
  • H1334 ST9 Light Ferrara Oak.
  • H1615 ST9 Romana Cherry.
  • H1887 ST9 Natural Stamburg Maple.
  • H1920 ST9 Natural Tyrolean Beech.
  • H3114 ST9 Tirano Pearwood.
  • H3303 ST10 Natural Arlington Oak.
  • H3704 ST15 Tabak Aida Walnut.
  • H3775 ST9 Light Tennessee Walnut.
