Description

A range of submersible pumps, designed for free-standing or pedestal usage.

Features:

  • Watertight fully flood-proof cast iron motor and hydraulics section.
  • Designed for a wide range of de-watering applications, including drainage, septic tanks and pumping effluent from locations below backwash level in accordance with DIN EN 12056.

Technical data:

  • Ingress protection (motor): IP68.
  • Temperature monitoring: TCS-Thermo-Control-System with thermal sensors in the stator to switch off the pump in the case of over heating and switch on automatically after cooling down.
  • Discharge volume: Up to 5 L/s.
  • Head (maximum): Approximately 10.5 m.

General information
Features

Watertight fully flood-proof cast iron motor and hydraulics section

Designed for a wide range of de-watering applications, including drainage, septic tanks and pumping effluent from locations below backwash level in accordance with DIN EN 12056

Uniclass 2015
Submersible pumps (Pr_65_53_24_86)Primary
Specification data - Submersible pumps
Product Reference

V1154 W

1¼"/ 1½", single phase.

V1254 W

1¼"/ 1½", single phase.

V1324 W

1¼"/ 1½", single phase.

V1504 W

1¼"/ 1½", single phase.

V1504 W

1¼"/ 1½", single phase.

V501X W

2", single phase.

V-VO 1354 W

2", single phase.

V-VO 1504 W

2", single phase.

V-VO 1804 W

2", single phase.

V1565 W

DN 65, single phase.

V1665 D

DN 65, single phase.

V1334 W

1¼"/ 1½", three phase.

V1404 D

2", three phase.

V1604 D

2", three phase.

V1804 D

2", three phase.

Product Options

Motor:

Three phase 400 V3 or single phase 220-240 V, 50 Hz.
