Dawson Pro - Concrete Effect Tile

Verified by manufacturer 9 months ago

Porcelain: 1600 x 3200 mm, 6 mm thick

PARKSIDE Variant:

Concrete effect tile.

Jump to:
BIM object icon
01162 762532 Website

Application

Interior and exterior wall and floor applications dependent on size.

Description

Dawson Pro complements the colour range of the Dawson collection by adding five warm shades on the same surface, creating a unique colour palette. With large slabs, 20 mm options, decors, mosaics and special pieces, the Dawson range can be used in any space.


Features and benefits:

  • Concrete effect finish.
  • Unique colour palette in terms of breadth and variety.
  • Seven colours: Ivory, Cream, Clay, Taupe, Tobacco, Powder Blue and Mustard.
  • Three finishes available.
  • 13 different sizes.
  • 27 special pieces.
  • Options for use both internally and externally.


Standards:

  • Length & Width - Standard: ISO 10545-2; Requirement: ±0.6% ~ ±2mm; Established Value: Conforms.
  • Thickness - Standard: ISO 10545-2; Requirement: ±5% ~ ±0.5mm; Established Value: Conforms.
  • Straightness - Standard: ISO 10545-2; Requirement: ±0.5% ~ ±1.5mm; Established Value: Conforms.
  • Flatness - Standard: ISO 10545-2; Requirement: ±0.5% ~ ±2.0mm; Established Value: Conforms.
  • Rectangularity - Standard: ISO 10545-2; Requirement: 2 ±0.5% ~ ±2.0mm; Established Value: Conforms.
  • Resistance to high concentrations of alkalis and acids: GHA (standard - ISO 10545-13).
  • Resistance to low concentrations of alkalis and acids: NPD (standard - ISO 10545-13).

General information

Color

Black

Blue

Cream

Grey

Yellow

Finish

Matt

Grip

Textured

Material

Ceramic

Porcelain

Shape

Square

Rectangle

Hexagon

Mosaic.

Other

Shapes mosaic.

Length

1600 mm

1200 mm

750 mm

600 mm

900 mm

Show more

Width

3200 mm

1600 mm

2780 mm

2400 mm

1200 mm

Show more

Uniclass

Pr_35_93_96_19 Ceramic tilesPrimary

CAWS

M40/110 Tiling to

M40/120 Mosaic to

M40/5 Tiling to

M40/12 Mosaic to

Environmental information

Recycled content

%

Recycled content varies from 20-40% depending on colour and size.

BIM objects

BIM object icon

NBS BIM object standard

This BIM object has been authored to meet the requirements of the NBS BIM object standard.

Find out more about the NBS BIM object standard.

Platform Compatible Version
IFC
-

1

Revit
-

1

Literature

Dawson Pro - Concrete Effect Tiles

Dawson Pro - Concrete Effect Tiles
