CSG 11840 Crash Tested Full Depth Rising Security Bollard HVM - Security Bollard

Verified by manufacturer 2 days ago

Cova Security Gates Ltd

Crash-tested, hydraulically operated rising bollard, providing vehicle access control with proven impact resistance up to 40mph with pressure sensor safety feature.

Jump to:
BOS
+44 (0)1293 553888 Website

Application

The CSG 11840 hydraulic rising bollard is particularly suitable for protecting entrances and perimeters in high-risk and high-traffic environments such as retail sites, train stations, hotels, commercial warehouses, embassies, bus stations, ports, oil and gas refineries, and military installations. Its crash-tested design provides robust vehicle-borne threat mitigation while allowing controlled vehicle access when needed.

Ideal for locations where space, appearance, and operational flexibility are important, the CSG 11840 offers a safer, more adaptable solution than static bollards. Its hydraulic operation, combined with a pressure sensor safety feature, ensures both security and safe functionality.

The bollard’s ability to withstand multiple crash impacts, along with its quick-replacement ground socket, makes it an excellent choice for sites requiring rapid re-securing after an incident. Available in various RAL colours or with decorative sleeves, the bollard can be tailored to blend with its surroundings, making it as visually discreet as it is strong.

With easily accessible subsurface components for maintenance, the CSG 11840 is a reliable, efficient, and low-disruption solution for securing critical access points in demanding environments.

Description

The CSG 11840 is a crash tested, hydraulically operated bollard. It is an alternative to a static bollard where access is required, but crash tested for added security from a counter attack.


Features and benefits:

  • PAS 68:2010 and CWA 16221 crash rated bollard.
  • Standard rise time of six seconds.
  • Accumulators can be incorporated to provide emergency fast operation (EFO).
  • On power failure the standard HPU can be manually hand pumped to raise the bollard and gravity lowered by release valve.
  • Pressure sensor facility detects any obstruction on the rise cycle, and stops and reverses this automatic bollard on contact.
  • Manual or automatic controls.
  • Mechanical locking.
  • Operates at low and high weather extremes.
  • Available as standard in a number of durable finishes to any standard RAL colour, or with an optional selection of sleeves to suit the environment or location.
  • Hand built in the UK.
  • Warranty, service and maintenance available.

General information

Color

Beige

Black

Blue

Bronze

Brown

Show more

Finish

Galvanized

Powder-coated

Material

Steel

Shape

Circle

Width

219 mm

Height

1000 mm

Warranty description

-

Manufacturer guidance

Warranty, service and maintenance available.

Consult manufacturer for details.

Uniclass

Pr_20_76_08_12 Carbon steel rising bollardsPrimary

CAWS

Q50/190 Bollards

Q50/31 Bollards

Q50/194 Retracting bollards

SKU Code

CSG11840

Specification data - Carbon steel rising bollards

Standard

In accordance with PAS 68.

Guidance for specification option:

Test rating: PAS 68: 2010 V7500 (N2)/64/90:1.0/19.4.

Automation

-

Method of operation

Hydraulic with manual override.

Guidance for specification option:

  • Programmable Logic Controller (PLC).
  • Hydraulic power unit (HPU).
  • Manual hand pump for manual operation.
  • Operational usage: 100% duty cycle.

Electrical supply

400 V, 50 Hz, three phase rated at 10 Amp.

Controllers

Pressure sensor facility.

Dimensions

-

Size and profile

ø219 mm.

Height

1000 mm.

Top profile

Flat.

Base

Flat.

Finishes

-

Applied finish

Hot dipped galvanized and powder-coated.

Colour

RAL colour.

Guidance for specification option:

Insert colour requirement.

Accessories

Not required.
DDA banding.
Accumulators.

Operating time

Raise speed: 4–6 seconds.
Emergency fast raise (EFO): 1–2 seconds.
Lower speed: gravity fall.

Sustainability data

Material

Steel
