CS Acrovyn® HRB4C / HRB4CAL series Hand/Crash Rails
Description

A range of combined hand/crash rails, with a single piece, flat Acrovyn® or Acrovyn® 4000 cover.

Features:

  • Designed for severe duty use in corridors.
  • Single piece Acrovyn® or Acrovyn® 4000 cover over a continuous aluminium retainer.
  • HRB4C variants feature Rapid Fix brackets for fast installation and easy maintenance.
  • Anti-ligature options (HRB4CAL) feature a continuous aluminium bracket.
  • Free floating cover design allows it to flex on impact and shock-absorbing bumper cushion provides additional impact protection.
  • Available in 27 Acrovyn® profile colours and 8 Acrovyn® 4000 profile colours.

General information

Uniclass 2015

Pr_35_90_43_86 Wall protection panelsPrimary

CAWS

N10/184 Wall rails

P20/170 Proprietary

Specification data - Wall protection panels

Product Reference

Acrovyn® HRB4C Hand/ Crash Rail

Acrovyn® HRB4CALHand/ Crash Rail - Anti-ligature option

Acrovyn® 4000 HRB4C-N Hand/ Crash Rail

Acrovyn® 4000 HRB4CAL-N Hand/ Crash Rail - Anti-ligature option

Colour

As schedule ___

Accessories

Not required

Acrovyn® end cap

Acrovyn® external corner

Standard product features

Dimensions:

140 mm overall height.

Stock length:

4000 mm - Acrovyn®, 3000 mm - Acrovyn® 4000.

Fixings:

800 mm maximum centres.

Product Options

Acrovyn® HRB4C and Acrovyn® 4000 HRB4C-N Hand/ Crash Rail:

  • Overall projection from wall: 76 mm.
  • Mounted on standard Rapid Fix brackets.

Acrovyn® HRB4CAL and Acrovyn® HRB4CAL-N Hand/ Crash Rail:

  • Overall projection from wall: 76 mm.
  • Features anti-ligature continuous, powder coated aluminium bracket.

Colours:

- Acrovyn®:

11 Alpine Blue/ 12 Cobalt/ 16 Harvest Gold/ 17 Sherbet/ 23 Spring Green/ 24 Dove/ 26 Taupe/ 34 Zest/ 100 Eggshell/ 101 French Cream/ 105 Mocha/ 112 Pacific Blue/ 129 Yale Blue/ 136 Pearl Grey/ 162 Charcoal/ 520 Imperial Purple/ 801 Grey Cloud/ 845 Spectrum Red/ 879 Dusty Jade/ 933 Mission White/ 4005 Plum/ 5018 Lagoon/ 6033 Mint Turquoise/ 7024 Graphite/ 7039 Iron/ 8019 Earth/ 9003 Snow White.

- Acrovyn® 4000:

100 Eggshell/ 101 French Cream/ 105 Mocha/ 129 Yale Blue/ 136 Pearl Grey/ 162 Charcoal/ 520 Imperial Purple/ 933 Mission White.
