CS Acrovyn® ECR80 Heavy Duty Crashrail

Name: CS Acrovyn® ECR80 Heavy Duty Crashrail
Brand: hPGRo8w5aaTsUgpeHTwsps
SKU: 5zaqsCtZ4MMCy8Q2UZfSQR

Construction Specialties (UK) Ltd

Heavy duty crashrail, mounted on Rapid Fix brackets; used for providing impact protection to interior walls.

Jump to:

+44 (0)1296 652800 www.c-sgroup.co.uk

Description

A range of 201 mm high crash rails, featuring a curved Acrovyn® or Acrovyn® 4000 cover over a continuous aluminium retainer.

Features:

Designed for heavy duty applications, for extensive impact protection.

Free-floating design flexes on impact.

Continuous shock-absorbing cushion for increased impact protection.

Available in 27 Acrovyn® profile colours, or 8 Acrovyn® 4000 profile colours.

Three mounting options for varying stand-offs, including Rapid Fix bracket option.

General information

Finish	Cover - Pebblette texture
Features	Cover flexes on impact, continuous aluminium retainer
Material	Acrovyn® over continuous aluminium retainers
Size	201 x 34 x 4000 mm (204 x 81 x 4000 - including fixing brackets)
Uniclass 2015	Pr_35_90_43_86 Wall protection panelsPrimary
CAWS	N10/184 Wall rails P20/170 Proprietary

Specification data - Wall protection panels

Product Reference

Acrovyn® BCR80 Crash Rail

Acrovyn® ECR80 Crash Rail

Acrovyn® SCR80 Crash Rail

Acrovyn® 4000 BCR80-N Crash Rail

Acrovyn® 4000 ECR80-N Crash Rail

Acrovyn® 4000 SCR80-N Crash Rail

Colour

As schedule ___

Accessories

Not required

Acrovyn® end cap

Acrovyn® external corner

Acrovyn® return to wall end cap

For ECR80 / ECR80-N profiles only.

Standard product features

Depth of rail:

34 mm.

Stock length:

4000 mm - Acrovyn®, 3000 mm - Acrovyn® 4000.

Fixings:

600 mm maximum centres.

Product Options

Acrovyn® BCR80 and Acrovyn® 4000 BCR80-N Crash Rails:

Overall projection: 46 mm.

Mounted on rubber cushions.

Acrovyn® ECR80 and Acrovyn® 4000 ECR80-N Crash Rails:

Overall projection: 81 mm.

Mounted on Rapid Fix brackets.

Acrovyn® SCR80 and Acrovyn® 4000 SCR80-N Crash Rails:

Overall projection: 34 mm.

Surface mounted.

Colour:

- Acrovyn®:

11 Alpine Blue/ 12 Cobalt/ 16 Harvest Gold/ 17 Sherbet/ 23 Spring Green/ 24 Dove/ 26 Taupe/ 34 Zest/ 100 Eggshell/ 101 French Cream/ 105 Mocha/ 112 Pacific Blue/ 129 Yale Blue/ 136 Pearl Grey/ 162 Charcoal/ 520 Imperial Purple/ 801 Grey Cloud/ 845 Spectrum Red/ 879 Dusty Jade/ 933 Mission White/ 4005 Plum/ 5018 Lagoon/ 6033 Mint Turquoise/ 7024 Graphite/ 7039 Iron/ 8019 Earth/ 9003 Snow White.

- Acrovyn® 4000:

100 Eggshell/ 101 French Cream/ 105 Mocha/ 129 Yale Blue/ 136 Pearl Grey/ 162 Charcoal/ 520 Imperial Purple/ 933 Mission White.
