Description

Aluminium sliding door sets, of slim but strong frame design, for residential use.

Features:

  • Dual colour available.
  • Multi chamber weather stripped profiles with polyamide thermal breaks.
  • Nitrile rubber glazing gaskets.
  • Size (w x h, maximum): 6408 x 2500 mm - sliding four pane.
  • Two, three or four leaves.
  • Stainless steel track and wheels giving easy operation.
  • Traditional design with slim sight lines.
  • Maximum leaf weight: 80 kg.

Performance (BS 6375-1):

  • 300 Pa Water tightness (Class 7A); 300 Pa Air Permeability (Class 2); 800 Pa Wind Resistance (Class A2).

General information
Size

Insert requirements.

Finish

Anodized

To BS 3987.

Powder coated gloss, colour

To EN 12206-1: 2004, insert colour.

Powder coated matt, colour

To EN 12206-1: 2004, insert colour.

Powder coated satin, colour

To EN 12206-1: 2004, insert colour.

Features

Dual colour available

Multi chamber weather stripped profiles with polyamide thermal breaks

Nitrile rubber glazing gaskets

Size (w x h, maximum): 6408 x 2500 mm - sliding four pane

Two, three or four leaves

Stainless steel track and wheels giving easy operation

Traditional design with slim sight lines

Maximum leaf weight: 80 kg

Uniclass 2015 Sliding door and partition sets (Pr_30_59_24_80)
Specification data
Product Reference

Crown Patio Doors

Leaves

2

3

4

As drawing

As schedule

Size

Insert requirements.

Finish

Anodized

To BS 3987.

Powder coated gloss, colour

To EN 12206-1: 2004, insert colour.

Powder coated matt, colour

To EN 12206-1: 2004, insert colour.

Powder coated satin, colour

To EN 12206-1: 2004, insert colour.

Glazing

24

28

32

Handle

Insert handle and colour requirements from Options.

Accessories

None

Internal thumbturn to lock

Standard product features

Hardware:

Multi-point lock with lever and cylinder.

Product Options

Glazing:

24, 28 or 32 mm as standard. Insert details of glass and spacer dimensions, emissivity, safety and solar control.

Handle:

Curved pull handles.
