Description

Aluminium casement windows with side, top hung or fixed lights, for residential use.

Features:

  • Dual colour available.
  • Drained and ventilated glazing; nitrile rubber gaskets.
  • Multi chamber weather stripped profiles with polyamide thermal breaks.
  • Range of frame profiles; corner junctions 90–270°.
  • Size (maximum) as manufacturer's table.
  • Trickle ventilators.
  • Steel frame slim line replacement version available.

Performance:

Meets BS 6375-1: 2009: Class 9A (600Pa) Water Tightness; Class 3 (600 Pa) Air Permeability; Class B5 (2000 Pa) Wind Resistance. Economic slimline casement range with high levels of thermal insulation, can achieve Window Energy Rating of 'A'.

General information
Size

Insert details.

Finish

Anodized

To BS 3987.

Powder coated gloss, colour

To EN 12206-1: 2004, insert colour.

Powder coated matt, colour

To EN 12206-1: 2004, insert colour.

Powder coated metallic, colour

To EN 12206-1: 2004, insert colour.

Powder coated satin, colour

To EN 12206-1: 2004, insert colour.

Features

Dual colour available

Drained and ventilated glazing; nitrile rubber gaskets

Multi chamber weather stripped profiles with polyamide thermal breaks

Range of frame profiles; corner junctions 90–270°

Size (maximum) as manufacturer's table

Trickle ventilators

Steel frame slim line replacement version available

Uniclass 2015 Aluminium window units (Pr_30_59_98_02)
Specification data
Product Reference

Crown Casement Windows

Profile -
Frame

Insert details.

Casement

Insert details.

Size

Insert details.

Finish

Anodized

To BS 3987.

Powder coated gloss, colour

To EN 12206-1: 2004, insert colour.

Powder coated matt, colour

To EN 12206-1: 2004, insert colour.

Powder coated metallic, colour

To EN 12206-1: 2004, insert colour.

Powder coated satin, colour

To EN 12206-1: 2004, insert colour.

Glazing

24 mm

28 mm

32 mm

Handles

Cranked key locking silver anodized

Cranked key locking white

Cranked key locking polished gold

Cranked key locking gold

Cranked key locking ebony

Straight key locking silver anodized

Straight key locking white

Straight key locking polished gold

Straight key locking gold

Straight key locking ebony

Hinges

Austenitic stainless steel friction stays

Austenitic stainless steel restrictor friction stays

Austenitic stainless steel fire escape friction stays

Stainless steel friction stays

Stainless steel restrictor friction stays

Stainless steel fire egress friction stays

Standard product features

Locking:

Multi point locking with two-position keeps, shootbolts and mushroom cams.

Product Options

Frame and casements:

A choice of profiles is available; consult with manufacturer.

Glazing:

24, 28 or 32 mm as standard. Insert details of glass and spacer dimensions, emissivity, safety and solar control.
