Crossgrip TPO
Application

Suitable to protect flat roofs from heavy foot traffic, dropped tools and maintenance equipment.

Description

Flexible and lightweight, the thermoplastic polyolefin (TPO) roof walkway pads are supplied in a rolled format. They are designed to be loose-laid with no fixing required, so can be installed quickly and easily – even in adverse weather conditions.

Crossgrip TPO sits at a raised height of 12 mm to help elevate workers above the roof surface, while the durable, welded construction contours to all ethylene propylene diene monomer (EPDM) and TPO membrane roofs, effectively protecting the roof surface from any potential damage.

The embossed surface ensures a firm underfoot grip, making it the ideal EPDM or TPO roofing mat for staff and maintenance workers who need safe access on the roof.

Features and benefits:

  • Embossed surface.
  • Durable, welded construction.
  • Two-layer construction.
  • Manufactured from flexible TPO.
  • Loose-lay; no fixing required.
  • Supplied in 10 m rolls.
  • Certified slip resistance (DIN 51130: R9).
  • Excellent drainage (DIN 51130: V10).
  • Contours to and protects the EPDM and TPO roof membranes.

Wind resistance:

In laboratory conditions, on a flat, stable platform at The University Of Hertfordshire's School of Aerospace, Automotive & Design Engineering, Crossgrip TPO remained stable in wind speeds of up to 55 mph (88 km/h).

Application:

Suitable to protect flat roofs from heavy foot traffic, dropped tools and maintenance equipment.

General information
Size

12 x 10 000 x 610 mm

12 x 10 000 x 750 mm

Color

White, yellow

Features

Quick to install, stable in high winds, contours to roof structure and protects the, membrane, embossed surface, durable welded construction, good drainage, UV resistant

Material

Thermoplastic polyolefin

Shape

Rectangular

WarrantyDescription

4 years

Uniclass 2015
Pr_35_57_11_49 Loose-laid mattingPrimary
CAWS

N10/310 Loose laid matting

Specification data - Loose-laid matting
Product Reference

Crossgrip TPO

Purpose

Walkway matting

Colour

White

Yellow

Weight

5.2 kg/m²

Slip resistance

DIN 51130: R9, V10, ASTM 1677: 1.1/0.9

Wind resistance

When loose-laid, it can withstand winds of up to 55 mph (89 km/h)

Format

Supplied in 10 m rolls

Cleaning guidelines

Simply lift or roll to clean, can be cleaned with high-pressure hose

Size

12 x 10 000 x 610 mm

12 x 10 000 x 750 mm

Acoustic performance

Excellent sound absorption

FireRating

EN ISO 13501-1:2007-Dfl-S1

Standard product features

Colour:

Two standard colours available, with more colours available upon request. Consult manufacturer for details.

Features:

Quick to install; stable in high winds; contours to roof structure and protects the membrane. Embossed surface; durable, welded construction; good drainage, and ultraviolet-resistant.

Material:

Thermoplastic polyolefin.

Shape:

Rectangular.

Warranty description:

Four years.

Recyclability:

100% recyclable.

Country of manufacture:

UK and USA.

Environmental information
Recyclability

100% recyclable

Digital objects
PlatformCompatibleVersionCertified to
IFC
- 1 2.1
Revit
- 1 2.1
Download now from NBS National BIM Library
