COOL-LITE® SKN

Verified by manufacturer 1 month ago

COOL-LITE® SKN 075 II (on DIAMANT®)

Saint-Gobain Building Glass Variant:

High performance, solar control glass for glazing and façades.

Jump to:
+44 (0)1977 666118 Website

Application

COOL-LITE® SKN APPLICATIONS


Designed to enhance the performance and aesthetics of your projects, COOL-LITE® SKN is the ideal choice for a wide range of applications:


CURTAIN WALLING

Enhance the energy efficiency and visual appeal of your curtain wall systems.


EXTERIOR STRUCTURAL SEALANT GLAZING

Achieve seamless, modern designs with superior structural integrity.


DOUBLE-SKIN APPLICATIONS

Optimise thermal performance and natural ventilation in double-skin façades.


OVERHEAD AND ATRIA GLAZING

Maximise natural light while minimising solar heat gain in skylights and atria.


LARGE GLAZED AREAS IN RESIDENTIAL PROJECTS

Embrace open, airy living spaces with superior thermal comfort, whilst mitigating excessive heat build-up in sun-exposed areas, particularly south-facing elevations.


For further information, visit our website - click here

Description

COOL-LITE® SKN – SOLAR CONTROL GLASS


Our COOL-LITE® SKN range is specifically designed to provide neutral solar control for commercial buildings alongside large glazed apertures in residential projects. This range of solar control glass has been carefully engineered to prioritise comfort and energy efficiency, making it an ideal solution for combating overheating whilst enhancing the overall energy performance of a building space.

From aesthetics to interior design, noise levels, and natural light, various factors contribute to the overall feeling of comfort and well-being within a building. This is why a thoughtfully designed and carefully constructed space has the power to elevate our mood, enhance productivity, and even promote better health.


The COOL-LITE® SKN range inherently considers our daily comfort in its purpose as a façade glass. Its high-performance double silver-coated design is used across a range of applications where large glazing is required to offer high levels of light transmittance with a low solar factor.


The COOL-LITE® SKN solar reflective glass range is available in a range of coatings to suit different requirements and is applied to our PLANICLEAR® range of glass as standard. However, when used in combination with STADIP® SILENCE or the standard STADIP® range, it can also provide noise reduction alongside safety and security, respectively.

General information

Color

Clear

Finish

Other

Material

Glass

Shape

Rectangle

Height

4 mm

6 mm

8 mm

10 mm

Uniclass

Pr_25_71_33_02 Annealed glass sheetsPrimary

CAWS

H13/115 Structural glass assembly

H11/110 Curtain walling

H10/10 Patent glazing

H10/115 Patent glazing

Specification data - Annealed glass sheets

Thickness

4 mm.

Guidance for specification option:

On demand.

6 mm.

Guidance for specification option:

As standard.

8 mm.

Guidance for specification option:

As standard.

10 mm.

Guidance for specification option:

As standard.

Body colour

Clear.

Coating

-

Type

Solar.

Design

Solid.

Performance requirements

-

Light

To EN 410, 71% (transmittance).

Solar control

To EN 410, 36% (solar factor).

Thermal performance

To EN 673, 1.0 W/m²K.

Manufacturer guidance

Ug-Value.

Reflectivity

To EN410, 15% (inside reflection - LRI).
To EN410, 14% (outside reflection - LRe).

Glazing

DIAMANT®.

Dimensions

6000 x 3210 mm.

Guidance for specification option:

As standard.

18000 x 3210 mm.

Guidance for specification option:

On demand.

Sustainability data

Country of product manufacture

Germany

Recyclability

Saint-Gobain Glass products are manufactured using a minimum of 30% recycled content.

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

30 %
