Concrete Veneer Ceilings - Concrete veneer ceiling system
Verified by manufacturer 2 months ago
Perforated (acoustic) tiles
Perforated (acoustic) tiles
Concrete veneer ceiling tiles and wall panels.
Application
Internal ceiling tile applications.
Description
Lightweight concrete veneer ceiling panel system which contains a thin layer of real concrete with a fine perforation pattern
Features and benefits:
- Lightweight.
- Easy to handle and install.
- Can be supplied made-to-measure or cut to size on site using regular woodworking tools.
- Achieves a high level of sound absorption.
- Pressed onto a core of fire-retardant MDF.
- Matching wall system available (specified separately).
General information
Color | Grey White Black |
Finish | Cement |
Material | Concrete Medium density fibreboard (MDF) |
Shape | Square Rectangle |
Length | 600 mm |
Width | 600 mm |
Height | 16 mm |
Uniclass | |
CAWS | K40/115 Unit/ modular suspended ceiling system K40/10 Unit/ modular suspended ceilings |
Specification data - Modular suspended ceiling systems
Ceiling support | Manufacturer's standard. |
Support fasteners | Manufacturer guidanceInsert requirements, to suit substrate. |
Ceiling units | Natural white, 600 x 600 mm.Natural white, 1200 x 600 mm.Natural white, 1800 x 600 mm.Original, 600 x 600 mm.Original, 1200 x 600 mm.Original, 1800 x 600 mm.Vintage, 600 x 600 mm.Vintage, 1200 x 600 mm.Vintage, 1800 x 600 mm.Dark graphite, 600 x 600 mm.Dark graphite, 1200 x 600 mm.Dark graphite, 1800 x 600 mm.Stone grey, 600 x 600 mm.Stone grey, 1200 x 600 mm.Stone grey, 1800 x 600 mm.Manufacturer guidance16 mm fire-retardant MDF with a 1.5 mm-thick cement veneer to both sides. 0.6 mm-diameter nano-perforation in concrete; 10 mm-diameter perforation in MDF core; includes 0.2 mm-thick nonwoven acoustic fleece. Finish: Colourless super-matt 2C lacquer. |
Third-party certification | MDF certified, FSC/PEFC quality mark. |
System | Classic. Guidance for specification option: The CLASSIC model comes with a tegular edge and expose the T-24 grid. Modern. Guidance for specification option: The MODERN tile has a 4 mm joint all around the panel edges. System. Guidance for specification option: The SYSTEM tile can be used for high impact areas such as sports halls. The pre-mounted springs keeps the panels firmly in its’ place. Prestige. Guidance for specification option: The PRESTIGE tiles have a shiplap edge detail which conceals the suspension system but still allows easy access into the plenum. Used for a continuous ceiling with hairline joints. |
Edge banding | Concrete veneer. ABS. |
Reaction to fire | B-s1,d0 (to EN 13501-1). |
Weight | 12 kg/m². |
Sound absorption | αw (ISO 11654) = 0.50 (LM); NRC (ASTM - C423) = 0.70; SAA (ASTM - C423) = 0.72. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | Netherlands |
Material | Concrete Medium density fibreboard (MDF) |
