Concrete paver step treads and risers
Description

Concrete step treads and risers to match Marshalls Saxon, Perfecta and Conservation ranges of paving.

General information

Uniclass 2015

Pr_25_93_60_16 Concrete flagsPrimary

CAWS

Q25/31 Concrete flag paving

Q25/315 Concrete flags

Specification data - Concrete flags

Product Reference

Concrete paver step treads and risers

Treads

-

Colour/ Finish

Conservation charcoal

Smooth.

Conservation silver grey, smooth

Conservation silver grey, textured

Perfecta buff

Textured.

Perfecta natural

Textured.

Saxon buff

Smooth.

Saxon natural

Smooth.

Sizes

400 x 400 x 50

18.2–18.4 kg/unit.

400 x 400 x 65

Conservation charcoal and Conservation silver grey, textured only. 23.6 kg/unit.

450 x 450 x 50

22.8–24.0 kg/unit.

Visibility strip

Black

As standard.

White

Risers

-

Colour/ Finish

Conservation charcoal

Smooth.

Conservation silver grey, smooth

Conservation silver grey, textured

Perfecta buff

Textured.

Perfecta natural

Textured.

Saxon buff

Smooth.

Saxon natural

Smooth.

Sizes

400 x 170 x 50

7.7–7.8 kg/unit.

400 x 170 x 65

Conservation charcoal and Conservation silver grey, textured only. 10.0 kg/unit.

450 x 170 x 50

8.6–9.1 kg/unit.

Visibility strip

Black

As standard.

White

Standard product features

General:

  • Compliant with BS EN 1339:2003.
  • 450 x 450 x 50 mm and 400 x 400 x 50 mm treads are available from stock.

Product Options

Colour/ Finish:

Available in smooth and textured finishes from the Saxon, Perfecta and Conservation ranges. Tread front edges are finished to match, and have a 3 mm chamfer.

Visibility strip:

55 mm wide visibility strips are set 35 mm back from the edges of treads and at the top of risers. Standard strip colours meet BS 8300 Light Reflectance Values (LRVs).

Risers:

– Sizes:

Riser heights can be matched to project requirements.
