Concept 70 - Sheet vinyl

Application

Suitable for flooring in restaurants, hotels, schools, hospitals, nursing homes, childcare facilities and public buildings.

Description

Concept 70 is a multi-purpose floor and a suitable solution for any location.


Features and benefits:

  • Multi-purpose vinyl flooring available in 2 and 4 m width rolls. Easy to install and maintain, with an ultra-hygienic coating and minimal seams to allow easy cleaning.
  • The 0.70 mm wear-resistant layer is durable in harsh conditions. Available in a wide variety of designs.
  • Wear layer polyurethane (PUR) treatment: Hyperguard+.
  • Suitable for underfloor heating.
  • Ten-year warranty.
  • CE marked.
  • Indoor air quality rating: A+.
  • Acoustic insulation: 5 dB.
  • Total weight: 2198 g/m².
  • Curling: ≤8 mm.
  • Wear layer: 0.7 mm.
  • Dimensional stability: ≤0.05%.
  • Electrical resistance: ≤109 Ohm.
  • Heat insulation: 0.0108 m²K/W.
  • Indoor emission rating: A+.
  • Level of use: 23–33–43.
  • Light fastness: 6.
  • Residual indentation: ≤0.04 mm.
  • Slip resistance: R10.
  • Static electrical propensity: ≤2 kV (antistatic).
  • Thermal conductivity: 0.25 W/(m.K).
  • Fire rating (to EN 13501): Bfl-s1.
  • Wear layer polyurethane (PUR) treatment: Hyperguard+.

General information

Finish

Embossed

Color

Brown

Beige

Grey

Red

Yellow

Show more

Material

PVC

Shape

Rectangular

WarrantyDescription

Ten years

Uniclass 2015

Pr_35_57_71_67 Polyvinyl chloride (PVC) sheetsPrimary

CAWS

M50/150 Sheeting

M50/20 Sheeting

Specification data - Polyvinyl chloride (PVC) sheets Enhanced data

Use class

Class 23–33–43.

Slip potential

-

Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

R10.

Width

2000 mm.

4000 mm.

Thickness

2.0 mm.

Colour and pattern

Aspin T25.

Aspin T35.

Aspin T49.

Product Reference

Concept 70 - Sheet Vinyl

Length

25000 mm.

Digital objects

Platform Compatible Version Certified to
IFC
-

1

2.0
Revit

Revit 2017

1

2.0
Download now from NBS National BIM Library
