Concealed Soleco Metal Door Frames for Timber Doors
Verified by manufacturer 4 months ago
Concealed steel door frames for solid core timber door.
Application
Steel doors frames suitable for residential applications.
Description
Concealed steel door frame for solid core timber door.
Features and benefits:
- Minimalist design.
- Easy to fit.
- Durable.
- Environmentally friendly.
- Designed to work with UK building methods.
General information
Finish | Powder-coated Unfinished |
Material | Steel Stainless steel |
Shape | Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Warranty description | Five year |
Uniclass | |
CAWS | L20/370 Door frames |
Specification data - Carbon steel door frames
Fire performance | None - NFR.FD30.FD60.Manufacturer guidanceDoor thickness: 44 mm NFR / FD30 54 mm FD60 |
Configuration | Double-leaf frame.Single-leaf frame. |
Steel grade | Manufacturer's standard. |
Dimensions | |
Width and height | Manufacturer guidanceInsert requirements or refer to a schedule. |
Threshold | None.Flat bottom threshold. |
Finish | |
Coating | Powder-coated.Unfinished for on-site painting. |
Colour | RAL 9010 30% gloss smooth.Guidance for specification option: As standard. RAL.Guidance for specification option: Insert requirements. None (unfinished). |
Type | Concealed frame – invisible. |
Material | Folded Zintek mild steel. Guidance for specification option: As standard. Folded stainless steel. |
Hinges | Tectus Concealed Hinge FD60. Butt Hinge – NFR. Stainless Steel Lift Off – NFR. |
Sustainability data
Contains Red List materials | No |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Recyclability | Recyclable |
Literature
Simplis Soleco Steel Door Frames Brochure
Case studies
Past Projects
