Combison Uno Ds
Application

For use as a sound-absorbing ceiling, and for sound insulation between rooms if the partitions do not extend all the way up to the soffit. Also suitable for sound reduction of vertical noise generated by ventilation, footsteps, etc.

Description

For use as a sound-absorbing ceiling, and for sound insulation between rooms if the partitions do not extend all the way up to the soffit. Also suitable for sound reduction of vertical noise generated by ventilation, footsteps, etc. Ecophon Combison Uno Ds is installed in a suspended grid system, creating a ceiling with a smooth appearance. The bevelled edges create a narrow groove between each tile. The tiles are demountable.

The system consists of Ecophon Combison Uno Ds tiles and Ecophon Connect grid systems, with an approximate weight of 11 kg/m².

Features and benefits:

  • The tiles are manufactured from high-density glass wool, with a bonded gypsum board (13 mm) on the back of the tile.
  • The visible surface has an Akutex™ FT coating and the edges are primed.are primed.
  • For best performance and system quality, Ecophon Connect grid and accessories should be used.
  • The grid is manufactured from galvanized steel.


General information

Finish

Akutex FT

The surface allows almost 100% of the sound energy to penetrate into and be absorbed by the glass wool. Primed edges.

Color

White

White Frost (standard) – white 500, nearest NCS colour sample S 0500-N, 85% light reflectance (of which more than 99% is diffuse reflection).


Features

Installed in a suspended grid system, creating a ceiling with a smooth appearance. The bevelled edges create a narrow groove between each tile. For best performance and system quality, use Ecophon Connect grid and accessories. Patented system

Material

High-density glass wool

With a bonded gypsum board (13 mm thick) on the back of the tile.

Galvanized steel

Grid.

Shape

Square

Size

600 x 600 mm

35 mm thickness.

WarrantyDescription

Full warranty available upon request

Uniclass 2015

Ss_30_25_22_90 Unit/ modular suspended ceiling systemsPrimary

CAWS

K40/10 Suspended ceilings

K45/13 Suspended ceiling system alterations

K45/160 Board-suspended ceiling system alterations

K40/55 Insulation

K40/265 Infill units

K45/130 Unit-suspended ceiling system alterations

K45/12 Existing suspended ceiling system

K45/120 Existing suspended ceiling system

K40/285 Insulation

K40/115 Unit/ modular suspended ceiling system

K40/105 Suspended ceiling system

Specification data - Unit/ modular suspended ceiling systems Enhanced data

Ceiling support

Interlocking Connect™ T24 HD grid

Support fasteners

Adjustable hangers/ wire

105 mm overall system depth.

Ceiling units

High-density glass wool tiles

Barriers in ceiling void

-

Acoustic barriers

Combison Barrier

Glass wool construction with an aluminium foil surface.

Combison XR

Glass wool construction.

System accessories

None

Connect™ Lighting Clip

Product Reference

Combison Uno Ds

Grid colour

Black 01 matt

Grey 01 metallic

White 01

Trim

Connect™ Angle Trim C1

Weight

11 kg/m² (approximate, including Connect grid system)

Demounting depth (minimum)

40 mm

Indoor climate

Recommended by the Swedish Asthma and Allergy Association. Certified as A+ by French VOC. Emission classification of building materials: M1

Moisture resistance

The tiles withstand a permanent ambient relative humidity (RH) of up to 70% at 25°C without sagging, warping or delaminating (EN 13964)

Fire safety

Complies with BS EN 13501-1, Class A2-s1, d0. Non-combustible to EN ISO 1182

Sound absorption

200 mm-deep system: in accordance with EN ISO 11654, Class C

Sound insulation

41 dB Dnfw weighted normalized flanking level difference, ISO 10848-2

Cleaning

The ceiling system can withstand daily dusting and vacuum cleaning, and weekly wet-wiping

Environmental information

Contains Red List materials

No

Country of material origin

Sweden

Embodied carbon

No performance declared

Recycled content

58
