Cold Melt® Liquid Applied Membrane - Liquid-Applied Roof Waterproofing

Verified by manufacturer 2 days ago

Built-up roof (protected warm)

Proteus Waterproofing Variant:
Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

  • BRE Certificate

    BRE Certificate

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

  • ISO 14001 Environmental Management Systems

    Certificate type

A multi-component polyurethane-based liquid applied membrane for use as a zero falls waterproofing system for inverted roofs, flat roofs, podium decks, balconies, blue roofs and living/green roofs.

Jump to:
+44 (0)1268 777871 Website

Application

For prepared concrete, asphalt and wood substrates.


Satisfactory for use as a protected waterproofing layer on zero fall roofs and flat roofs with limited or pedestrian access in the following specifications:

  • Inverted roofs.
  • Protected roofs, e.g. covered by pavers or other suitable protection.
  • Green roof and roof gardens.

Description

A polyurethane two-part, elastomeric, cold liquid applied membrane, waterproofing system. The system provides seamless leak protection to inverted roofs, flat roofs, podium decks, balconies, blue roofs and living/green roofs.


Features and benefits:

  • BBA Certified - 16-5311.
  • Inverted roofs.
  • Podium decks.
  • Balconies.
  • Blue roofs.
  • Extensive green roofs.
  • Intensive green roofs.
  • Biodiverse roofs.
  • Roof gardens.
  • Can be laid on a flat roof deck with zero falls.
  • Cold application removes risk of fire.
  • Seamless waterproofing.
  • High solids at 99.6% (by weight) provide an elastomeric, impervious, tough and seamless membrane, preventing moisture transmission.
  • Extremely low odour in wet state, curing to an inert system.
  • Durable and does not embrittle with age.
  • Performance equalling lifetime of building, when covered.
  • Recycled rubber crumb and other renewable elements contributes to sustainability.
  • Chemical resistant.
  • Flexible and crack resistant, including crack bridging at low temperatures.
  • High bond strength.
  • Resistant to dynamic stress.
  • NHBC Standards 2023.


All works shall be carried out in accordance with the requirements of BS 6229: 2018 Code of Practice for flat roofs with continuously supported coverings, and BS 8217: 2004 Reinforced bitumen membranes for roofing Code of Practice.


System components:

  • Cold Melt® Membrane — a two-part, liquid-applied polyurethane consisting of a resin component and a hardener.
  • Cold Melt® DPM Primer — a two-part primer for use in preparing concrete substrates and polymer-modified sand/cement screeds with a moisture content greater than 75% relative humidity, prior to application of the carrier membrane.
  • Pro-Prime® SA — a single component primer for use in preparing timber and concrete substrates and polymer-modified sand/cement screeds with a moisture content less than 75% relative humidity, prior to application of the carrier membrane.
  • Pro Vapour Control/Carrier Membrane SA — a 0.6 mm thick, self-adhesive carrier membrane for use over primed substrates prior to application of Cold Melt® Membrane.
  • Pro-Grit 0.7–1.2 mm — kiln-dried quartz sand broadcast into wet Cold Melt® DPM, to produce a mechanical key for sand/cement screeds and bedding mortars when used as an alkali protection layer.


Consult manufacturers literature for component specific technical information, and for details regarding preliminaries, structure and loadings, liability information, and further guidelines.

General information

Color

Black

Guidance for specification option:

Cold Melt®.

White

Guidance for specification option:

Cold Melt® UV Top.

Grey

Guidance for specification option:

Cold Melt® UV Top.

Manufacturer guidance

  • Nine additional colours standard for Cold Melt® UV Top.
  • Available in RAL & British Standard colours, subject to quantity and extended deliver times.

Finish

Matt

Material

Polyurethane

Guidance for specification option:

Elastomeric.

Resin

Rubber

Shape

Formless

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

25 year

Guidance for specification option:

Guarantee.

Uniclass

Ss_30_40_30_42 Liquid-applied inverted roof covering systemsPrimary
Ss_45_40_47_40 Intensive green roof systems
Ss_30_40_30_43 Liquid-applied warm roof covering systems
Ss_30_40_30_07 Blue roof systems
Ss_45_40_47_09 Brown roof systems
Ss_30_40_30_40 Liquid-applied cold roof covering systems
Ss_45_40_47_28 Extensive green roof systems
Ss_45_40_47_75 Semi-intensive green roof systems

CAWS

J31/353 Waterproof coating

J31/10 Warm deck roof coating

J31/110 Cold deck roof coating

J31/120 Warm deck roof coating

J31/130 Inverted roof coating

Q37/120 Simple intensive green roof

Q37/130 Extensive green roof

Q37/110 Intensive green roof

J31/5 Cold deck roof coating

J31/12 Inverted roof coating

Specification data - Liquid-applied inverted roof covering systems

Preparation

-

Horizontal work

Pro-Prime® SA.

Guidance for specification option:

For Concrete/ Timber Deck.

  • For best results ensure that surfaces to be primed are free from oil or dust.
  • Apply Pro-Prime® SA by roller or brush at a rate min of 5 m²/lit (the green colour will indicate the treated area); refill roller if ‘cobwebbing’ appears. Avoid puddling of the primer.
  • Drying time will be affected by surface porosity, film thickness and temperature and can vary between 40-90 minutes.
  • Pro-Prime® SA will remain tacky even after dry.
  • To test, use the back of a glove or dry object to press into the primer and remove; there should be no transfer of primer when the primer is ready. It is essential that sufficient drying time is allowed as any entrapment of solvent will result in blistering/ delamination.
  • Only prime areas that will be covered with Pro-Carrier SA within 2-3 hours. Avoid walking over areas already primed.

Cold Melt® DPM.

Guidance for specification option:

For green concrete.

  • Only to be used after consultation with Proteus technical team.
  • Minimum rate 0.4 kg/m².
  • Cold Melt® DPM can be used on green concrete with a RH over 75%.

Pro-Sealer WB.

Guidance for specification option:

For  Brickwork/ Blockwork/ Porous Surfaces.

  • Apply Pro-Sealer WB to all areas to be waterproofed at a minimum rate of 0.25 L/m² (Porous substrates may require a second coat).
  • Ensure that the primer is fully cured prior to the waterproofing system being applied.

Pro-Epoxy Primer.

Guidance for specification option:

For Metal Substrates.

  • Apply Pro-Epoxy Primer to all areas to be waterproofed at a minimum rate of 0.17 L/m².
  • Ensure that the primer is fully cured prior to the waterproofing system being applied.

Skirtings and vertical work

Pro-Prime® SA.

Guidance for specification option:

For Concrete/ Timber Deck.

  • For best results ensure that surfaces to be primed are free from oil or dust.
  • Apply Pro-Prime® SA by roller or brush at a rate min of 5 m²/lit (the green colour will indicate the treated area); refill roller if ‘cobwebbing’ appears. Avoid puddling of the primer.
  • Drying time will be affected by surface porosity, film thickness and temperature and can vary between 40-90 minutes.
  • Pro-Prime® SA will remain tacky even after dry.
  • To test, use the back of a glove or dry object to press into the primer and remove; there should be no transfer of primer when the primer is ready. It is essential that sufficient drying time is allowed as any entrapment of solvent will result in blistering/ delamination.
  • Only prime areas that will be covered with Pro-Carrier SA within 2-3 hours. Avoid walking over areas already primed.

Cold Melt® DPM.

Guidance for specification option:

For green concrete.

  • Only to be used after consultation with Proteus technical team.
  • Minimum rate 0.4 kg/m².
  • Cold Melt® DPM can be used on green concrete with a RH over 75%.

Pro-Sealer WB.

Guidance for specification option:

For  Brickwork/ Blockwork/ Porous Surfaces.

  • Apply Pro-Sealer WB to all areas to be waterproofed at a minimum rate of 0.25 L/m² (Porous substrates may require a second coat).
  • Ensure that the primer is fully cured prior to the waterproofing system being applied.

Pro-Epoxy Primer.

Guidance for specification option:

For Metal Substrates.

  • Apply Pro-Epoxy Primer to all areas to be waterproofed at a minimum rate of 0.17 L/m².
  • Ensure that the primer is fully cured prior to the waterproofing system being applied.

Carrier membrane

-

Type

Pro-Carrier Membrane SA.

Guidance for specification option:

  • Self-adhesive bituminous waterproofing membrane (self-adhesive low-thickness bituminous compound self-protected by an aluminium film).
  • 0.6 mm thick.
  • Apply the Pro-Carrier Membrane SA to the primed areas of waterproofing to be installed.
  • Side laps should be a minimum of 100 mm with end laps a minimum of 150 mm. The Carrier Membrane should be applied to all vertical surfaces.

Fixing

Pro-Prime® SA.

Liquid-applied waterproofing

-

Type

Cold Melt® Membrane.

Guidance for specification option:

Cold Melt® Flexible Polyurethane Membrane Resin at minimum rate 2.5 kg/m², the product is applied in two applications, the first at 1.5 kg, and the second at 1.0 kg to all vertical surfaces, and in one application to all horizontal surfaces.


Surface treatment

Not required.

Cold Melt® UV Top to exposed details.

Guidance for specification option:

  • For exposed details only.
  • High solids polyurethane liquid resin.
  • Tested in accordance with the requirements of BS EN 1504-2.
  • Available white, black, grey or in nine other standard colours. Available in RAL & British Standard Colours subject to quantity and extended delivery times. Consult manufacturer for details.

Insulation

-

Type

Proteus Pro-Therm PIR.

Guidance for specification option:

Proteus Pro-Therm Insulation PIR is a fibre-free rigid polyisocyanurate (PIR) insulation core faced with coated glass tissue on one side and bituminized glass tissue with polypropylene fleece on the other. The PIR fibre free insulation core is temperature tolerant and withstands the application of hot bitumen and asphalt to the surface at up to 230°C.

Proteus Pro-Therm HP PIR.

Guidance for specification option:

Proteus Pro-Therm HP PIR used either stand alone or with tapered or flat board insulation as a premium performance board, providing a slim solution for use on new and existing roofs with timber or concrete decks.

Proteus Pro-Therm HP PIR Plus.

Guidance for specification option:

Proteus Pro-Therm HP PIR Plus used either stand alone or with tapered or flat board insulation as a premium performance board, providing a slim solution for use on new and existing roofs with timber or concrete decks.

Proteus Pro-Therm Mineral Wool.

Guidance for specification option:

The Proteus Pro-Therm Mineral Wool has been specifically developed for use on flat roof and refurbishment projects. The product is manufactured with an integral mineral coating fibre fleece, which for adhered membranes, secured a strong bond between membrane and insulation whilst limiting the amount of adhesive required. The insulation is compatible with all commonly used flat roof membranes including bitumen and liquid applied membranes.

Proteus Pro-Therm Cellular Glass.

Guidance for specification option:

Proteus Pro-Therm Cellular Glass consists of a Cellular Glass slab, the upper surface is unfaced.


The insulation is manufactured from specially graded recycled glass (≥60%) and natural raw materials which are available in abundant supply (sand, dolomite, lime). The product is totally inorganic, contains no ozone depleting propellants, flame resistant additives or binders. Without VOC or other volatile substances.

Proteus Pro-Therm VIP.

Guidance for specification option:

Proteus Pro-Therm VIP Insulation is a high performance Vacuum Sealed Insulation Panel with a microporous core which is evacuated, encased and sealed in a thin, gas-tight envelope, giving outstanding thermal conductivity, with the thinnest possible solution to insulation problems, suitable for a variety of roof types and designs.

Proteus Pro-Therm (XPS) Upstand Board.

Guidance for specification option:

Consult manufacturer for details.

Proteus Pro-Therm Non-Combustible Upstand Board 56mm.

Guidance for specification option:

Consult manufacturer for details.

Proteus Pro-Therm Mineral Wool with Proteus Pro-Cold detailing.

Guidance for specification option:

Consult manufacturer for details.

Proteus Pro-Therm PIR with Proteus Pro-Cold detailing.

Guidance for specification option:

Consult manufacturer for details.

Fixing

Pro-Bond Foaming adhesive.

Guidance for specification option:

For warm deck roof build-ups.

Compatible with the following vapour barriers and substrates: Bituminous vapour control layers, concrete decks, galvanized metal decks, mastic asphalt, oriented strand boards, plywood, proprietary vapour barriers and existing bituminous built up roofing.

Compatible with the following insualtion boards: bituminous felt faced, cork insulation, cellular glass insulation, expanded polystyrene (eps), extruded polystyrene (xps), glass tissue faced, rock fibre and wood fibre.

Manufacturer guidance

Consult manufacturer for details.

Water control layer

Not required.

Proteus Low-K Water Reducing Layer.

Guidance for specification option:

  • Type: Spun bonded polyethylene geotextile .
  • All abutting sheets must have minimum 300 mm overlaps.
  • When used for attenuation all joints are to be taped.


Ballast

Not required - see Surface finish property.

Fill to perimeter upstands

-

Manufacturer guidance

Insert requirements or omit.

System accessories

Not required.

Proteus Pro-Living Biodiverse Roof.

Proteus Pro-Living Blue Roof.

Proteus Pro-Living Extensive Green Roof.

Proteus Pro-Living Green Roof.

Proteus Pro-Living Intensive Green Roof.

Proteus Pro-Living Semi-Intensive Wildflower Roof.

Manufacturer guidance

Consult manufacturer and insert requirements or omit.

Execution

-

Manufacturer guidance

Please consult the manufacturer for execution requirements, including substrate requirements and preparation.

System completion

Wet electronic leak test.

Guidance for specification option:

  • Completed after system installation.
  • Required for all inverted/ buried systems prior to the waterproofing membrane being covered.

Air and vapour control layer

Pro-Vapour Control/Carrier Membrane SA.

Guidance for specification option:

For built-up warm roofs, built-up protected roofs and built-up inverted roofs.

Air and vapour control layer fixing

Pro-Prime® SA.

Substrate

Structural concrete.

Plywood deck.

Cross Laminated Timber deck.

Green concrete.

Brickwork.

Show more

Manufacturer guidance

Consult manufacturer for details on substrate requirements.

Colour

Black.

Manufacturer guidance

Cold Melt®.

Surface finish

Stone ballast.

Guidance for specification option:

Minimum 50 mm.

Pre-cast concrete paving slabs.

Guidance for specification option:

Minimum 50 mm.

Pro-Living® Green Roofs.

Solids content

99.6% (Cold Melt®); 95% (Cold Melt® UV Top).

Density

1 kg/L (Cold Melt®); 1.6 kg (Cold Melt® UV Top).

Curing time

24 hours (10°C); 12 hours (20°C); 8 hours (30°C).

Manufacturer guidance

Foot traffic time.

Overcoating

24—36 hours (10°C); 12—36 hours (20°C); 6—24 hours (30°C).

Working time

30 minutes (10°C); 15 minutes (20°C); <10 minutes (30°C).

Reaction to fire classification

Class E.

Guidance for specification option:

To Commission Decision 2010/85/EU.

Container capacity

5 kg.

Guidance for specification option:

Per box.

10 kg.

Guidance for specification option:

Per box.

15 kg.

Guidance for specification option:

Per box.

Manufacturer guidance

Cold Melt®.

Life expectancy

Building design life (when covered).

Third-party certification

BBA Certificate.

Guidance for specification option:

Certified for use as a waterproofing layer in inverted roofs and protected flat roofs, including zero pitched roofs.

Sustainability data

Material

Polyurethane

Guidance for specification option:

Elastomeric.

Resin

Rubber

Third party certifications

Third party certifications

BBA Agrément Certificate

BBA Agrément Certificate

BBA - Proteus Cold Melt®

BRE Certificate

BRE Certificate

BRE - Cold Melt® DPM - Adhesive Bond Strength Test

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO 9001 Quality Management

ISO 14001 Environmental Management Systems

ISO 14001 Environmental Management Systems

ISO 14001 Environmental Management Systems

Literature

Manual - Proteus Cold Melt®

Manual - Proteus Cold Melt®

Product Data Sheet - Proteus Cold Melt®

Product Data Sheet - Proteus Cold Melt®

Product Data Sheet - Proteus Pro-Prime® SA

Product Data Sheet - Proteus Pro-Prime® SA

Product Data Sheet - Proteus Pro-Therm XPS Upstand Board

Product Data Sheet - Proteus Pro-Therm XPS Upstand Board

Product Data Sheet - Proteus Pro-Therm EPS Plus Premium

Product Data Sheet - Proteus Pro-Therm EPS Plus Premium

Product Data Sheet - Proteus Pro-Therm Non-Combustible Upstand Board (60mm)

Product Data Sheet - Proteus Pro-Therm Non-Combustible Upstand Board (60mm)

Product Data Sheet - Proteus Pro-Therm Non-Combustible Upstand Board (56mm)

Product Data Sheet - Proteus Pro-Therm Non-Combustible Upstand Board (56mm)

Product Data Sheet - Proteus Pro-Therm XPS Plus

Product Data Sheet - Proteus Pro-Therm XPS Plus

Product Data Sheet - Proteus Pro-Therm Low-K

Product Data Sheet - Proteus Pro-Therm Low-K

Product Data Sheet - Pro-Sealer WB

Product Data Sheet - Pro-Sealer WB

Material Safety Data Sheet - Proteus Cold Melt® DPM Primer (Hardener)

Material Safety Data Sheet - Proteus Cold Melt® DPM Primer (Hardener)

Material Safety Data Sheet - Proteus Cold Melt® DPM Primer (Resin)

Material Safety Data Sheet - Proteus Cold Melt® DPM Primer (Resin)

Material Safety Data Sheet - Proteus Cold Melt® UV Top (Hardener)

Material Safety Data Sheet - Proteus Cold Melt® UV Top (Hardener)

Material Safety Data Sheet - Proteus Cold Melt® UV Top (Resin)

Material Safety Data Sheet - Proteus Cold Melt® UV Top (Resin)

Product Data Sheet - Proteus Cold Melt® DPM Primer

Product Data Sheet - Proteus Cold Melt® DPM Primer

Product Data Sheet - Proteus Cold Melt® UV Top

Product Data Sheet - Proteus Cold Melt® UV Top

Material Safety Data Sheet - Proteus Pro-Joint Tape SA

Material Safety Data Sheet - Proteus Pro-Joint Tape SA

Material Safety Data Sheet - Proteus Pro-Protection Board

Material Safety Data Sheet - Proteus Pro-Protection Board

Product Data Sheet - Pro-Protection Board

Product Data Sheet - Pro-Protection Board

Material Safety Data Sheet - Proteus Pro-Bond Foaming

Material Safety Data Sheet - Proteus Pro-Bond Foaming

Product Data Sheet - Proteus Pro-Bond Foaming

Product Data Sheet - Proteus Pro-Bond Foaming

Product Data Sheet - Pro-Tool Surface Cleaner

Product Data Sheet - Pro-Tool Surface Cleaner

Case studies

Case Study - Proteus Cold Melt® - Battersea Cats & Dogs Home

Case Study - Proteus Cold Melt® - Battersea Cats & Dogs Home

Case Study - Proteus Cold Melt® & Proteus Pro-Living® - Cygnet Hospital

Case Study - Proteus Cold Melt® & Proteus Pro-Living® - Cygnet Hospital

Case Study - Proteus Cold Melt® & Proteus Pro-Living® - KBS Builders Ltd, Greenwich

Case Study - Proteus Cold Melt® & Proteus Pro-Living® - KBS Builders Ltd, Greenwich

Case Study - Proteus Hot Melt® and Proteus Cold Melt® - Nashmills

Case Study - Proteus Hot Melt® and Proteus Cold Melt® - Nashmills

Similar products from Proteus Waterproofing

Proteus Hot Melt® System  - Monolithic Structural Waterproofing

Proteus Hot Melt® System - Monolithic Structural Waterproofing

Proteus Pro-BW® Plus System

Proteus Pro-BW® Plus System

Proteus Pro-Cold System - Waterproofing Liquid Applied System

Proteus Pro-Cold System - Waterproofing Liquid Applied System

Proteus Pro-Living® Easy Green Modular Tray

Proteus Pro-Living® Easy Green Modular Tray
