Coated glass which works on the outer surface of any window to reduce (and in most cases prevent) the formation of external condensation on modern, highly efficient glazing.
The Guardian ClimaGuard® range is designed for use in insulating glass in residential, commercial and architectural projects. The low-emissivity coatings provide excellent thermal insulation with a neutral appearance. ClimaGuard® coated glass can be combined with clear float, SatinDeco, LamiGlass and SunGuard Solar ranges of Guardian products to provide sophisticated solutions for energy conservation.
Further processing:
Applications:
Benefits:
Standards:
Guardian Europe has ISO 9001 accreditation for the manufacture of float glass at all of its European based float glass plants. Guardian Low-emissivity coated glass complies with the requirements of EN 1096-4: ‘Glass in Building – Coated Glass’. Guardian also has ISO 14001 Environmental Management System standard.
Features | High thermal insulation, neutral appearance, igh light transmission, optimized solar heat gain |
Material | Float Glass |
Uniclass 2015 | |
CAWS | H10/10 Patent glazing H10/115 Patent glazing H11/110 Curtain walling H13/115 Structural glass assembly L40/210 Putty-fronted single-glazing L40/230 Bead-fixed single-glazing L40/250 Bead-fixed single-glazing L40/260 Bead-fixed single-glazing L40/310 Bead-fixed single-glazing L40/330 Bead-fixed single-glazing L40/350 Bead-fixed single-glazing L40/370 Bead-fixed insulating glass units L40/371 Bead-fixed insulating glass units L40/372 Bead-fixed insulating glass units L40/380 Bead-fixed insulating glass units L40/381 Bead-fixed insulating glass units L40/40 Putty-fronted single-glazing L40/410 Single-glazing into grooves L40/430 Single-glazing into grooves L40/450 Single-glazing into grooves L40/470 Zipper gasket glazing L40/490 Single-sided gasket glazing L40/50 Bead-fixed single-glazing L40/530 Internal tape glazing L40/55 Bead-fixed insulating glass units L40/57 Bead-fixed insulating glass units L40/58 Bead-fixed insulating glass units L40/90 Internal tape glazing |
Product Reference | Climaguard® |
Type | - |
Glass | ExtraClear FloatExtraClear LamiGlass |
Coating | ClimaGuard® A+ (Typical 4-16-4 double glazing performance: 1.2 U-value, 73–76% g value, 80% light transmission)ClimaGuard® DS (Typical 4-16-4 double glazing performance: 1.3 U-value, 69% g value, 70% light transmission)ClimaGuard® A 1.1 (Typical 4-16-4 double glazing performance: 1.1 U-value, 65% g value, 79% light transmission)ClimaGuard® A 1.0 (Typical 4-16-4 double glazing performance: 1.0 U-value, 54% g value, 72% light transmission) |
Thickness | See Options for Clear Float and Laminated glass thicknesses. |
Standard product features | Size: - Manufacturer's standard (other sizes available):
|
Product Options | Coating: - ClimaGuard® A+: This is for use in residential or commercial buildings. It offers a U-value as low as 1.2 W/m²K in an argon filled double glazing unit and is ideal where window energy ratings apply and high solar gain is factored as a requirement, utilising high g-values above 71% with clear float and 73-74% with low iron glass. - ClimaGuard® DS: This range is for use in residential building. It offers a U-value as low as 1.3 W/m²K in an Argon filled double glazing unit. ClimaGuard® A 1.1 Specifically designed for use in architectural buildings. It has a very neutral appearance and can achieve U-values of 1.1 W/m²K in an argon filled double glazing unit. - ClimaGuard® A 1.0: Lowest U-value, low-E glass range ideal for use in architectural buildings. It offers a U-value as low as 1.0 W/m²K in an Argon filled double glazed unit. By utilising a high light transmission of 72% and mid range solar factor of 54% this product is ideal for specifications like the Passivhaus window specification where it provides a manageable level of solar heat gain. Thickness:
|
Platform | Compatible | Version | Certified to |
---|---|---|---|
![]() | Revit 2016 | 4 | 2.0 |
![]() | IFC2X3 | 3 | 1.3 |
