ClimaGuard® A+
A low-e (emissivity) glass, specifically designed to have a low 1.2 U-value (W/m²K) combined with the highest level of solar heat gain possible.
- Curtain walling.
- Edge-worked.
- Manufactured into suitable double or triple glass insulating units.
The Guardian ClimaGuard® range is designed for use in insulating glass in residential, commercial and architectural projects. The low-emissivity coatings provide excellent thermal insulation with a neutral appearance. ClimaGuard® coated glass can be combined with clear float, SatinDeco, LamiGlass and SunGuard Solar ranges of Guardian products to provide sophisticated solutions for energy conservation.
Further processing:
- Cut to size.
- Toughening.
- Heat soaking.
- Heat strengthening.
- Laminating.
- Drilling.
- Notching.
- Edgeworking.
- CNC shaping.
- Manufactured into suitable double or triple glass insulating units.
Applications:
- Curtain walling.
- Edge-worked.
- Manufactured into suitable double or triple glass insulating units.
Benefits:
- Excellent thermal insulation performance in insulating glass units.
- Low U-values may be used to satisfy national and local building codes and regulations.
- High light transmission exploiting the use of natural daylight.
- May be utilised to provide optimum solar gain.
- Readily available and easily processed.
- Neutral appearance.
- Reduces cold down draughts increasing usable space in rooms.
- Satisfies Window Energy Rating (WER) requirements.
Standards:
Guardian Europe has ISO 9001 accreditation for the manufacture of float glass at all of its European based float glass plants. Guardian Low-emissivity coated glass complies with the requirements of EN 1096-4: ‘Glass in Building – Coated Glass’. Guardian also has ISO 14001 Environmental Management System standard.
Features | High thermal insulation, neutral appearance, igh light transmission, optimized solar heat gain |
Material | Float Glass |
Uniclass 2015 | |
CAWS | H10/10 Patent glazing H10/115 Patent glazing H11/110 Curtain walling H13/115 Structural glass assembly L40/210 Putty-fronted single-glazing |
Product Reference | Climaguard® |
Type | - |
Glass | ExtraClear FloatExtraClear LamiGlass |
Coating | ClimaGuard® A+ (Typical 4-16-4 double glazing performance: 1.2 U-value, 73–76% g value, 80% light transmission)ClimaGuard® DS (Typical 4-16-4 double glazing performance: 1.3 U-value, 69% g value, 70% light transmission)ClimaGuard® A 1.1 (Typical 4-16-4 double glazing performance: 1.1 U-value, 65% g value, 79% light transmission)ClimaGuard® A 1.0 (Typical 4-16-4 double glazing performance: 1.0 U-value, 54% g value, 72% light transmission) |
Thickness | See Options for Clear Float and Laminated glass thicknesses. |
Standard product features | Size: - Manufacturer's standard (other sizes available):
|
Product Options | Coating: - ClimaGuard® A+: This is for use in residential or commercial buildings. It offers a U-value as low as 1.2 W/m²K in an argon filled double glazing unit and is ideal where window energy ratings apply and high solar gain is factored as a requirement, utilising high g-values above 71% with clear float and 73-74% with low iron glass. - ClimaGuard® DS: This range is for use in residential building. It offers a U-value as low as 1.3 W/m²K in an Argon filled double glazing unit. ClimaGuard® A 1.1 Specifically designed for use in architectural buildings. It has a very neutral appearance and can achieve U-values of 1.1 W/m²K in an argon filled double glazing unit. - ClimaGuard® A 1.0: Lowest U-value, low-E glass range ideal for use in architectural buildings. It offers a U-value as low as 1.0 W/m²K in an Argon filled double glazed unit. By utilising a high light transmission of 72% and mid range solar factor of 54% this product is ideal for specifications like the Passivhaus window specification where it provides a manageable level of solar heat gain. Thickness:
|
| Platform | Compatible | Version | Certified to |
|---|---|---|---|
 IFC | IFC2X3 | 3 | 1.3 |
 Revit | Revit 2016 | 4 | 2.0 |
