Chromatics Ultra Low E Units

Chromatics Ultra Low E Units

Chromatics Glass Ltd Third party certifications:
  • CWCT Certificate

    CWCT Certificate

    Certificate type

Shatterproof, fire-safe, opaque and low emission double glazed unit consisting of two safety glass panels and an incorporated coloured or print layer.

Jump to:
+44 (0)1904 439187

Can be used in part of the following:

  • Curtain walling.
  • Insulated glass units (IGUs).
  • Double glazed units (DGUs).
  • Spandrel panels.


Opaque coloured or printed safety glass double glazed unit, delivering an insulation value of at least 1.7 W/m²K.

This product is fire safe, with a reaction to fire performance of A2–s1,d0 to EN 13501-1: 2007 and A1: 2009.

Features and benefits:

  • Highly insulative, with a thermal transmittance (U-Value) of lower than 1.7 W/m²K.
  • Thermally safe.
  • Lightweight and shatterproof.
  • Not subject to UV degradation.
  • Will remain stable under extreme temperatures.
  • The high definition print layer can be either full colour or monochrome.
  • Low environmental impact.
  • Doesn’t contain heavy metals or toxic elements, and will not produce any volatile organic compounds (VOCs).
  • Allows for a range of design possibilities.
  • Durable; the print layer will retain its decorative appearance without significant change for at least 12 years, and the panel will remain functional for a lifespan of 25 years.
  • No rollerwave distortion - completely flat finish which will not allow show-through of adhesive.
  • Highly durable, UV stable and retains appearance and performance for years.
  • Easy to maintain, and can be quickly installed using standard glazing systems.
  • Acts as a barrier for electronic surveillance, helping to increase privacy.
  • Low environmental impact.
  • Can be installed in either portrait or landscape orientations.
  • Not susceptible to catastrophic nickel sulphide breaks.
  • Does not require toughening or heat-soaking.
  • Manufactured from renewable and recyclable materials.


Can be used in part of the following:

  • Curtain walling.
  • Insulated glass units (IGUs).
  • Double glazed units (DGUs).
  • Spandrel panels.

General information


Uniclass 2015

Pr_25_71_33_14 Composite glass sheetsPrimary


H11/110 Curtain walling

K13/160 Proprietary

L30/50 Purpose-made balustrades

L30/55 Proprietary balustrades

L30/550 Purpose-made balustrades

L30/560 Proprietary balustrades

Specification data - Composite glass sheets

Product Reference

Chromatics Ultra Low E Units

Glass type

Clear float

Low iron


3100 x 2500 mm (maximum finished panel size). Other sizes available on request, consult manufacturer for details.


Consult manufacturer and insert requirements.

Colour/ Finish

Colour layer

Available in any RAL design or RAL classic colour, consult manufacturer and insert requirement.

Print layer

Digital images can be used - consult manufacturer and insert drawing/ reference.

Standard product features

Technical characteristics:

  • Fire rating (to EN 13501-1: 2007 and A1: 2009): A2-s1,d0.
  • Impact resistance (to BS EN 12600): Class 2(B)2.

Product Options


Supplied to required size as finished panels.

Colour/ Finish:

- Print layer:

Provides an accurate reproduction of high-definition digital images and text. Digital images can be reproduced to full panel size or tiled over any number of panels. Consult manufacturer for details.

Third party certifications
  • Certified N950/10/16177A : Standard for systemised building envelopes
Similar products from Chromatics Glass Ltd
