Chromatics HD Printed Panels

Chromatics HD Printed Panels

Third party certifications:
  • CWCT Certificate

    CWCT Certificate

    Certificate type

Chromatics Glass Ltd

A HD digitally printed, lightweight, shatterproof safety glass panel, suitable for multiple exterior and interior cladding and glazing applications.

Jump to:
+44 (0)1904 439187 www.chromaticsglass.com
Application

Suitable for interior or exterior use, including:

  • Fire-rated facades.
  • Curtain walling.
  • Spandrels.
  • Rainscreens.
  • Feature walls.
  • Signage and wayfinding.
  • Partitioning and balustrades.
  • Security (product is bomb blast resistant).
  • As a fire-rated safety glass.

The product can be bonded with silicone, polyurethane and polysulphide based materials.

Description

HD digitally printed, lightweight, shatterproof safety glass panel comprising a laminate of safety glass, print layer and aluminium for exterior applications such as curtain walling, rainscreen and interior wall linings, feature walls and wayfinding or signage.

Can be specified to BS EN 12600 3(B)3 or to BS EN 12600 1(B)1. The product is rated A2-s1, d0 in reaction to fire performance to EN 13501-1: 2007 and A1: 2009.

Features and benefits:

  • Certified to EN 1542:1999: Integrity of laminates.
  • Half the weight of traditional laminated or toughened glass with printed interlayers.
  • Specified and installed by BAA and Network Rail.
  • Shatterproof; will retain integrity even if damaged.
  • Not susceptible to catastrophic nickel sulphide breaks.
  • Does not require toughening or heat-soaking.
  • UV stable.
  • No pin-holes.
  • No rollerwave distortion
  • Highly reflective, with a flat, opaque finish which will not allow show-through of adhesive.
  • Impervious to attack from the rear by adhesives and solvents. Approved fixing with Dow Corning and Sika.
  • Highly durable, UV stable and retains its appearance and performance for years.
  • Easy to maintain, and can be quickly installed using standard glazing systems.
  • Low environmental impact.
  • Does not contain solvents, heavy metals or toxic elements, and will not produce any volatile organic compounds (VOCs).
  • Can be installed in either portrait or landscape orientations.
  • Manufactured from renewable and recyclable materials.
  • Has a life expectancy of more than 25 years.

Applications:

Suitable for interior or exterior use, including:

  • Fire-rated facades.
  • Curtain walling.
  • Spandrels.
  • Rainscreens.
  • Feature walls.
  • Signage and wayfinding.
  • Partitioning and balustrades.
  • Security (product is bomb blast resistant).
  • As a fire-rated safety glass.

The product can be bonded with silicone, polyurethane and polysulphide based materials.

General information

Size

Uniclass 2015

Pr_25_71_33_14 Composite glass sheetsPrimary

CAWS

H11/110 Curtain walling

H92/120 Rainscreen cladding

K13/160 Proprietary

L30/50 Purpose-made balustrades

L30/55 Proprietary balustrades

Show more
Specification data - Composite glass sheets

Product Reference

Chromatics HD Printed Panels

Glass type

Clear float

Low iron

Self-cleaning

On request.

Thickness

Consult manufacturer for details and insert requirements. 6 mm standard thickness.

Size

3110 x 2500 mm (maximum finished panel size). Other sizes available on request, consult manufacturer for details.

Impact resistance (to BS EN 12600)

Class 1(B)1

Class 3(B)3

Colour/ Finish

Print layer with a choice of digital image - consult manufacturer and insert drawing/ reference.

Standard product features

Technical characteristics:

  • Fire rating (to EN 13501-1: 2007 and A1: 2009): A2-s1,d0.
  • Impact resistance – BSEN12600 3(B)3 to BS EN 12600: 1B1
  • Laminate integrity (to BS EN 1542: 1999): Pull-off tests exceeded.
  • Light transmittance: 0.

Product Options

Size:

Supplied as stock or to required size as finished panels. Other sizes may be available, consult manufacturer for details.

Colour/ Finish:

Digital images can be reproduced to full panel size or tiled over any number of panels. Consult manufacturer for details.

Third party certifications
  • Certified N950/10/16177A. : Standard for systemised building envelopes
