Charisma PVC-U Vertical Sliding Sash Windows

Verified by manufacturer 5 months ago

Eurocell plc Third party certifications:
  • BBA Agrément Certificate

    BBA Agrément Certificate

    Certificate type

Traditional aesthetics with all the thermal-efficiency, low-maintenance benefits of PVC-U.

Jump to:
+44 (0)1773 842100 Website

Application

PVC-U sliding sash windows for any building project, including residential

Description

High-performance PVC-U windows for all domestic, commercial or public-sector building projects. Allows specifiers to create a window in the sophisticated style of the Georgian era with the additional performance benefits provided by modern PVC-U materials.


Features and benefits:

  • Cutting-edge design with sliding upper and lower window panes, both of which also tilt to enable easy cleaning
  • Sophisticated hardware design means sashes have a smooth glide operation
  • Triple brush seals for exceptional draught proofing, plus 24 mm low 'E' glazing – for outstanding thermal efficiency
  • Anti-jemmy bar to prevent break-ins and reinforced hardware for optimum security
  • Provides a means of escape from fire under Building Regulations (E&W) Approved Document B
  • Overhead vent to supply constant fresh air
  • Low-line beads and gaskets to improve sight lines and maximise natural light within the property
  • A range of high-quality aesthetic options enabling you to tailor the appearance of each window, including decorative horns and Georgian bar fixings
  • Ovolo sculpted sill, slot-in end caps and cruciform moulding
  • Ten-year guarantee against warping, dis-colouring and cracking

General information

Color

Cream

White

Grey

Manufacturer guidance

MTO colours available

Finish

Woodgrain

Smooth

Material

PVC-U

Guidance for specification option:

Unplasticized polyvinyl chloride.

Shape

Rectangle

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

Ten year

Uniclass

Pr_30_59_98_92 Unplasticized polyvinyl chloride (PVC-U) window unitsPrimary

CAWS

L10/30 PVC-U windows

L10/350 PVC-U windows

Product range

Windows

Specification data - Unplasticized polyvinyl chloride (PVC-U) window units

Third-party certification

To KM 32821; KM 52187.

Guidance for specification option:

Other: Accreditation by the British Board of Agrément (BBA) and British Standards Institute (BSI).

Dimensions and configurations

125 mm front-to-back.

Product performance

-

Durability

-

Operation and strength characteristics

Internal webs for maximum stability and impact resistance.

Frame

-

Profile

Chamfered.

Sculpted ovolo.

Reinforcement

Galvanized steel.

Colour and texture

Cream.

Guidance for specification option:

Extruded.

Golden oak.

Guidance for specification option:

Cream.

Irish oak.

Guidance for specification option:

Cream.

Rosewood.

Guidance for specification option:

Cream.

White.

Guidance for specification option:

Extruded.

Ventilator

Overhead ventilator.

Guidance for specification option:

Overhead vent to supply constant fresh air.

Glazing or infill

-

Requirements

24 mm low 'E' glazing units.

Hardware

Anti-jemmy bar and triple brush seals.

Operation

-

Type

Manual.

Guidance for specification option:

Smooth glide operation.

Fixing features

Georgian bar fixings.

Width

400–1600 mm.

Guidance for specification option:

Consult manufacturer and insert requirements.

Height

640–2400 mm.

Guidance for specification option:

Consult manufacturer and insert requirements.

Internal

Cream.

Guidance for specification option:

Extruded.

Golden oak.

Guidance for specification option:

Cream.

Irish oak.

Guidance for specification option:

Cream.

Rosewood.

Guidance for specification option:

Cream.

White.

Guidance for specification option:

Extruded.

Show more

Accessories

None.

Cill Adapter end caps.

Guidance for specification option:

(standard, 150, 180 mm) - VSW205, VSW207, VSW208).

Glass Packer.

Guidance for specification option:

VSW203.

Spring balance fixing Kit.

Guidance for specification option:

VSW607S.

Fixing Cleat.

Guidance for specification option:

VSW608S.

Show more

Ironmongery

Complete with sash lock and pull handle.

Sustainability data

Country of product manufacture

United Kingdom

Material

PVC-U

Guidance for specification option:

Unplasticized polyvinyl chloride.

Recyclability

Eurocell Closed-Loop Recycling

Third party certifications

BBA Agrément Certificate

BBA Agrément Certificate

Charisma BBA Certificate 14/5154

Literature

Charisma Vertical Slider Windows 10 Year Product Guarantee Certificate

Charisma Vertical Slider Windows 10 Year Product Guarantee Certificate

Charisma Vertical Slider Windows Classic Steel Ali Product Specification

Charisma Vertical Slider Windows Classic Steel Ali Product Specification

Charisma Vertical Slider Windows Classic Thermal Inserts Product Specification

Charisma Vertical Slider Windows Classic Thermal Inserts Product Specification

Charisma Vertical Slider Windows Product Chart

Charisma Vertical Slider Windows Product Chart

Charisma Vertical Slider Windows Thermal Inserts Product Specification

Charisma Vertical Slider Windows Thermal Inserts Product Specification

Charisma Vertical Sliding Sash Windows Consumer Brochure

Charisma Vertical Sliding Sash Windows Consumer Brochure

Case studies

Landmark Refurb Project uses Charisma Vertical Sliders
