Cembrit Solid - Facade Panel

Name: Cembrit Solid - Facade Panel
Brand: Cembrit Ltd
SKU: xt9dBxJrDojmVUoRXYugxe

NBS BIM object standard

Verified by manufacturer 6 months ago

Cembrit Ltd

Third party certifications:

BBA Agrément Certificate
Certificate type

'A' fire rated, intensely pigmented acrylic coated fibre cement rainscreen façade panel.

Jump to:

+44 (0)203 3722300 Website

Application

Suitable for use as rainscreen cladding, rigid sheet cladding and soffits.

Description

A non-combustible, intensely pigmented, acrylic-coated fibre cement rainscreen cladding board.

Features and benefits:

Through-coloured.
Made to order special colours.
Disguises surface damage.
Intense colours.

General information

Color Choice of 18 colours.	Other
Material	Fibre cement
Shape	Rectangle
Length	2500 mm 3050 mm
Width	1250 mm
Height	8 mm

Uniclass	Pr_25_71_11_25 Fibre-reinforced cement boardsPrimary
CAWS	G20/950 Fascias/ barges/ soffits G20/99 Fascias/ barges/ soffits H20/150 Sheet cladding H20/155 Sheet cladding H92/120 Rainscreen cladding

Product range	Cladding Boards

Specification data - Fibre-reinforced cement boards

Standard	To BS EN 12467:2004, Class NT A41.
Fire rating	To BS EN 13501-1, Class A2-s1, d0.
Sheet size	-
Nominal thickness	8 mm.
Length	2500 mm. 3050 mm.
Width	1250 mm.
Edges	Colour on every surface and edge.
Finish as delivered	Acrylic coated, smooth surface.
Colour	S030-Solid Mercury. S071-Solid Orcus. S101-Solid Pluto. S131-Solid Deep Black. S151-Solid RAL 7016. S191-Solid Erebus. S212-Solid Luna. S282-Solid Saturn. S334-Solid Jupiter. S353-Solid Mars. S515-Solid Venus. S525-Solid Triton. S606-Solid Rhea. S616-Solid Ceres. S656-Solid Terra. S676-Solid Callisto. S747-Solid Neptune. S757-Solid Mimas. Special order. Insert requirement.

Product Reference	Cembrit Solid
Weight	14.2 kg/m².
Treatment	Air cured.
Fixing method	Rivet, screw, site bonding or mechanical secret fix (MSF).

Environmental information

Contains Red List materials	No
Country of product manufacture	Hungary
Embodied carbon Global warming potential (GWP): 1.79E+03 kg CO2-eq. Ozone depletion potential: 6.84E-07 kg CFC11-eq. Acidification potential of soil and water: 4.46E+00 kg SO2-eq. Eutrophication potential: 4.97E-01 kg PO43-eq. Photochemical ozone creation potential: 7.81E-01 kg ethene-eq. Abiotic depletion potential for non-fossil resources: 3.64E-02 kg Sb-eq. Abiotic depletion potential for fossil resources: 2.08E+04 MJ.	-
Recycled content Use of renewable primary energy excluding renewable primary energy resources used as raw materials: 2.64E+03 MJ. Use of renewable primary energy resources used as raw materials: 1.07E+03 MJ. Total use of renewable primary energy resources: 3.71E+03 MJ. Use of non-renewable primary energy excluding non-renewable primary energy resources used as raw materials: 2.28E+04 MJ. Use of non-renewable primary energy resources used as raw materials: 1.51E+03 MJ. Total use of non-renewable primary energy resources: 2.43E+04 MJ. Use of renewable secondary fuels: 5.61E-06 MJ. Use of non-renewable secondary fuels: 5.16E-05 MJ. Use of net fresh water: 7.32E+00 m³.	-

BIM objects

Platform	Compatible	Version
Revit	-	1
IFC	-	1

Literature

Cembrit Patina, Cover, Solid & Transparent - Cladding

Cembrit Cover & Solid Colours

Third party certifications
