Description

Heavy duty aluminium doors, designed for car showrooms, airports and shopping complexes.

Features and benefits:

  • The sliding door can operate in a bi-parting mode on a common track or in a passing mode using multiple tracks permitting numerous design configurations.
  • Includes a double polypropylene pile around all four sides. Can be provided with a flush fitting drained threshold.
  • Glide block keeps the central panels in the head ensuring silent and smooth operation.
  • Sliding doors are set on steel wheels, running on individual brass tracks.

Construction:

The door leaves are constructed using the same method as the hinged or pivot commercial door and are then inserted into the sliding door system framework. Two methods of construction are available:

  • Corner cleats and tie rods.
  • Welded construction using special aluminium cleats.

General information
Finish

Anodized bronze

To BS 3987.

Anodized silver

To BS 3987.

Anodized other

To BS 3987, insert colour.

Powder-coated single colour

To EN 12206-1: 2004, insert colour and gloss level.

Powder-coated dual colour

To EN 12206-1: 2004, insert colours and gloss levels.

Uniclass 2015 Sliding door and partition sets (Pr_30_59_24_80)
Specification data
Product Reference

CD Commercial Aluminium Doors

Arrangement

Bi-parting mode on a common track

Passing mode on multiple tracks

Finish

Anodized bronze

To BS 3987.

Anodized silver

To BS 3987.

Anodized other

To BS 3987, insert colour.

Powder-coated single colour

To EN 12206-1: 2004, insert colour and gloss level.

Powder-coated dual colour

To EN 12206-1: 2004, insert colours and gloss levels.

Glazing/ panel thickness

Single gazed units

Double glazed units

Standard product features

Size (maximum):

3000 x 3000 mm (ratio not to exceed 3:1).

Weight:

180 kg.

Weather performance:

Tested in accordance with BS 6375-1.
