CASEA Casuplast 1000
Application

For walls constructed out of low-, medium- and high-density blockwork and any other masonry substrate. The composition allows the product to be applied in one coat application.

Description

CASEA Casuplast 1000 is a factory-produced, one-coat gypsum plaster designed for machine application, using all suitable spray rendering machines, produced to DIN EN 13279-1. It is manufactured from a controlled blend of selected aggregates, gypsum and other components to give a high-quality plastering product which is suitable for use in internal plastering. The properties of this render make it suitable for application on low-, medium- and high-density substrates.

Benefits:

  • One coat machine application.
  • High yield.
  • Easy to work with.
  • Sustainable.
  • Applications of up to 15 mm in one pass.
  • The drying process can be sped up with a dehumidifier.
  • MG P IVa according to DIN 18550, and B4 according to EN 13279-1.
  • Manufactured in accordance with ISO 9001 and 14001, 'Quality and Environmental Management systems', and OHSAS 18001, 'Occupational Health and Safety Management'.

Applications:

For walls constructed out of low-, medium- and high-density blockwork and any other masonry substrate. The composition allows the product to be applied in one coat application.

General information

Uniclass 2015

Pr_35_31_64_35 Gypsum plastersPrimary

CAWS

M20/240 One coat proprietary plaster

M20/47 One coat proprietary plaster

Specification data - Gypsum plasters

Product Reference

CASEA Casuplast 1000

Standard product features

Technical characteristics:

  • Application temperature: 5–35°C, and free of frost.
  • Yield: 1000 L per 1000 kg.
  • Compressive Strength: ≥2.5 N/mm².
  • Flexural Strength: ≥1.0 N/mm².
  • Modulus of Elasticity: <2 kN/mm².
  • Average minimum thickness: 10 mm.
  • Consumption: 100 m² at 10 mm per tonne.
  • Water demand: Approximately 15 L per 30 kg.
  • Thermal conductivity: λR=0.36 W/mK.
  • Water vapour permeability: μ < 8.
  • Grain size: 0–1 mm.
  • Reaction to fire: A1 non-combustible.

Digital objects
PlatformCompatibleVersionCertified to
Revit
Revit 2017 1 2.1
IFC
- 1 2.1
