BS Classic Tile
QA Certificate
Certificate type
Solid colour, round studded, non-slip rubber resilient floor tiles with TXL surface treatment.
Suitable for interior use, including schools, hospitals, museums, offices and other places of work. Classification (to EN ISO 10874 (EN 685)): 21 (Residential); 34 (Commercial); 43 (Industrial).
Solid colour, round studded, non-slip rubber resilient floor tiles with TXL surface treatment.
The TXL surface treatment is a post vulcanization treatment that achieves a lower surface density whilst increasing surface resistance, enhancing cleaning, dirt and scratch resistant properties.
Application:
Suitable for interior use, including schools, hospitals, museums, offices and other places of work. Classification (to EN ISO 10874 (EN 685)): 21 (Residential); 34 (Commercial); 43 (Industrial).
Size | 500 x 500 mm |
Finish | Studded |
Features | Solid colour, round studded, non-slip rubber resilient floor tiles with TXL surface treatment |
Material | Rubber |
Shape | Square |
Uniclass 2015 | |
CAWS | M50/10 Resilient floor tiling M50/110 Resilient floor tiling |
Product Reference | BS Classic Tile |
Standard | To BS EN 14041 and BS EN 12199 |
Use class | To BS EN ISO 10874 class 21/ 34/ 43 |
Slip potential | - |
Slip Potential - Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum) | DS |
Size | 500 x 500 mm |
Thickness | 2.7 mm |
Colour and pattern | B12 SkyB18 LagoonG 810 CanvasG 811 SilverG 813 FalconG 814 TitaniumG 815 StoneG 816 GlacierM23 BrownV713 MeadowV755 LimeY507 HeliosY510 Orange |
Weight | 3.8 kg/m² |
Technical characteristics to EN 12199 | - |
Hardness (to ISO 7619) | Shore 90 |
Residual indentation (to EN/ISO 24343-1 (EN 433)) | 0.08 mm |
Abrasion resistance (to ISO 4649) | 160 mm³ |
Dimensional stability (to EN/ISO 23999 (EN 434)) | ±0.30% |
Flexibility (to EN/ISO 24344 Met. A Ø 20 mm (EN 435)) | Comply |
Colour fastness to artificial light (to ISO 105-B02 Met. 3) | Comply |
Cigarette burn (to EN 1399) | Comply |
Tear strength (to ISO 34-1 Met. B, procedure A) | Comply |
Technical characteristics to EN 14041 | - |
Fire behaviour (to EN 13501-1) | Class Bfl– s1 |
Technical characteristics, other | - |
Toxicity of decomposition gases (to DIN 53436 at 350°C) | Not toxic |
Resistance to stains (to EN/ISO 26987 (EN 423)) | ResistantDepending on concentration and time of contact: for specific agent contact manufacturer. |
Ramp slip resistance (to DIN 51130) | R9 |
Thermal resistance (to EN 12667) | 0.014 m²K/W |
Thermal conductivity (to EN 12667) | 0.20 W/m·K |
Electrical resistance (to EN 1081 Met. A) | >10^10 ohms |
Electrostatic charge (to EN 1815) | ≤2 kV (antistatic) |
Reduction of sound due to treading (to ISO 10140-3) | Up to 8 dB |
Castor chairs (to EN 425) | Suitable for W castors |
VOC emissions (CA Section 01350) | Comply |
VOC emissions (AgBB) | Comply |
Standard product features | Colour: 13 options. Features: Solid colour, round studded, non-slip rubber resilient floor tiles with TXL surface treatment. Finish: Studded. Material: Rubber. Shape: Square. Size: 2.7 x 500 x 500 mm. |
| Platform | Compatible | Version | Certified to |
|---|---|---|---|
 IFC | - | 1 | 2.1 |
 Revit | - | 1 | 2.1 |
QA Certificate
Eurofins: Indoor Air Comfort GOLD - Certified
Additional certifications:
- Émissions dans l’air intérieur: A+
- GECA: GECA 25-2011v2 - Certified
