BS Classic Tile
Application

Suitable for interior use, including schools, hospitals, museums, offices and other places of work.

Description

Solid colour, round studded, non-slip rubber resilient floor tiles with TXL surface treatment. The TXL surface treatment is a post vulcanization treatment that achieves a lower surface density whilst increasing surface resistance, enhancing cleaning, dirt and scratch resistant properties.


Features and benefits:

  • Solid colour, round studded, non-slip rubber resilient floor tiles with TXL surface treatment.

General information

Finish

Studded

Color

13 options.

-

Material

Rubber

Shape

Square

Size

500 x 500 mm

Uniclass 2015

Pr_35_57_71_73 Relief rubber tilesPrimary

CAWS

M50/10 Resilient floor tiling

M50/110 Resilient floor tiling

Specification data - Relief rubber tiles Enhanced data

Standard

To BS EN 14041 and BS EN 12199.

Use class

To BS EN ISO 10874 class 21/ 34/ 43.

Size

500 x 500 mm.

Thickness

2.7 mm.

Colour and pattern

B12 Sky.

B18 Lagoon.

G 810 Canvas.

G 811 Silver.

G 813 Falcon.

G 814 Titanium.

G 815 Stone.

G 816 Glacier.

M23 Brown.

V713 Meadow.

V755 Lime.

Y507 Helios.

Y510 Orange.

Product Reference

BS Classic Tile

Slip Potential - Slip resistance value (SRV) (minimum)/ Pendulum test value (PTV) (minimum)

Slip resistance to EN 13893 DS.

Weight

3.8 kg/m².

Hardness (to ISO 7619)

Shore 90.

Residual indentation (to EN/ISO 24343-1 (EN 433))

0.08 mm.

Abrasion resistance (to ISO 4649)

160 mm³.

Dimensional stability (to EN/ISO 23999 (EN 434))

±0.30%.

Flexibility (to EN/ISO 24344 Met. A Ø 20 mm (EN 435))

Complies.

Colour fastness to artificial light (to ISO 105-B02 Met. 3)

Complies.

Cigarette burn (to EN 1399)

Complies.

Tear strength (to ISO 34-1 Met. B, procedure A)

Complies.

Fire behaviour (to EN 13501-1)

Class Bfl– s1.

Toxicity of decomposition gases (to DIN 53436 at 350°C)

Not toxic.

Resistance to stains (to EN/ISO 26987 (EN 423))

Resistant.

Depending on concentration and time of contact: for specific agent contact manufacturer.

Ramp slip resistance (to DIN 51130)

R9.

Thermal resistance (to EN 12667)

0.014 m²K/W.

Thermal conductivity (to EN 12667)

0.20 W/m·K.

Electrical resistance (to EN 1081 Met. A)

>10^10 ohms.

Electrostatic charge (to EN 1815)

≤2 kV (antistatic).

Reduction of sound due to treading (to ISO 10140-3)

Up to 8 dB.

Castor chairs (to EN 425)

Suitable for W castors.

VOC emissions (CA Section 01350)

Complies.

VOC emissions (AgBB)

Complies.

Digital objects
Platform Compatible Version Certified to
IFC
-

1

2.1
Revit
-

1

2.1
Download now from NBS National BIM Library
Literature
Third party certifications

Additional certifications:

  • Émissions dans l’air intérieur: A+
  • GECA: GECA 25-2011v2 - Certified
