Blenheim Umbrella

Application

Suitable for any setting including schools, nurseries, universities, healthcare, leisure, hospitality and retail.

Uses include al fresco dining, a pub garden canopy, a playground shelter and a collapsible sun shelter for small budgets.

Description

A high strength shade and shelter structure that can be opened and closed as and when required. Fitted with waterproof fabric, the umbrella provides all year-round protection, yet as it is collapsible, it does not require structural calculations or building regulations.


The high quality, cost effective product is manufactured from commercial materials and has been designed to be put up and left all year round. The product has a life expectancy of 10–15 years.


It is available from 2.8 m x 2.8 m to 4.2 m x 4.2 m. Supporting post constructed from 76 mm thick precision engineered stainless steel. Main ribs and supporting ribs constructed from 42 mm and 38 mm stainless steel tube section.


Weather resistance:

The tensile fabric is UV stabilized offering the highest UV protection. It blocks up to 99% of the sun's harmful UV rays. It will not absorb moisture and is designed to perform well in all normal weather conditions.


Fire performance:

Tensile fabric tested to BS 7837.

General information

Color

Black

Blue

Green

Red

Silver

Show more

Material

Fabric

Stainless steel

Size

2.8 x 2.8 m

3 x 4 m

4.2 x 4.2 m

WarrantyDescription

Two/ ten years

Frame/ fabric.

Uniclass 2015

Pr_20_65_78_58 Open sided sheltersPrimary

CAWS

B91/330 Canopy

Specification data - Open sided shelters Enhanced data

Shelter description

Collapsible umbrella.

Dimensions

-

Plan size

2.8 x 2.8 m.

3 x 4 m.

4.2 x 4.2 m.

Height

[-].

Insert requirement.

Frame

-

Material

Stainless steel, grade 1.4301 (304).

Stainless steel, grade 1.4401 (316).

Roof covering

Waterproof tensile fabric.

590 g/m², 252/250 daN/5 cm strength.

Accessories

None.

Fabric side fills.

Guttering.

Heating.

Lighting.

Post pads.

Seating.

Signage.

Roof fabric colour

Black.

Champagne.

Night Blue.

Poppy.

Raspberry.

Show more

Digital objects

Platform Compatible Version Certified to
IFC
-

4

2.1
Revit
-

4

2.1
Download now from NBS National BIM Library
