Description

Constructed from 1.5 mm zinc protected steel sheets and joined together in a bonding process with a solid timber core. The door frame is manufactured from 1.6 mm profiled zinc protected steel. The Armourdoor blast door is tested to BS EN 13124-2 (EXR2 and EXR3) and has been tested to withstand up to a 12 kg charge detonated 5.5 m away from the door.

Common applications are plant and equipment and generator rooms, electrical sub stations, police stations and hospitals. Armourdoor AD50 can be installed internally or externally.

Features:

  • Leaf thickness of 50 mm and an infill composed of solid timber with integral steel stiffeners.
  • Door frame constructed from folded 1.6 mm zintec/ aluzinc steel.
  • The blast door is supplied with a variable sub frame to allow up to 30 mm tolerance for site installations.
  • The frame is fitted with dog bolts.
  • The door is supplied with a standard 15 mm rebated threshold and driveable thresholds available on request.
  • The door blade is fitted with an anti-jemmy astragal.

High security triple point sash lock with high security cylinders and are protected to reduce risk of key copying.

General information
Size

Insert w x h.

Finish

Powder coated, RAL

Insert requirement.

PVC laminate

Stainless steel

Features

Leaf thickness of 50 mm and an infill composed of solid timber with integral steel stiffeners

Door frame constructed from folded 1.6 mm zintec/ aluzinc steel

The blast door is supplied with a variable sub frame to allow up to 30 mm tolerance for site installations

The frame is fitted with dog bolts

The door is supplied with a standard 15 mm rebated threshold and driveable thresholds available on request

The door blade is fitted with an anti-jemmy astragal

High security triple point sash lock with high security cylinders and are protected to reduce risk of key copying

Uniclass 2015
Metal door leaves (Pr_30_59_23_53)Primary
Specification data - Metal door leaves
Product Reference

Armourdoor Blast Steel Door AD50

Size

Insert w x h.

Finish

Powder coated, RAL

Insert requirement.

PVC laminate

Stainless steel

Ironmongery

Manufacturer's list available, refer to guidance for details.

Accessories

15 mm rebated threshold

As standard.

Driveable threshold

Standard product features

Size:

  • Single: Width, 690–1390 mm. Height: No greater than 2900 mm.
  • Double: Width, 1290–2600 mm. Height: No greater than 2900 mm.
