BASF - MasterSeal M 689
Application

Used in a variety of waterproofing applications where a degree of chemical resistance is required. These include sewage effluent, and secondary containment bunds within the dirty water, chemical and petrochemical industries. Can be applied to the majority of substrates irrespective of falls. Spray delivered and ultra-fast cure enables easy application to form a monolithic waterproofing membrane on simple and complex surfaces.

Description

MasterSeal M 689 is a solvent free, two component waterproofing membrane. It is highly reactive and can only be applied by special two component spray equipment.

Features and benefits:

  • Application to vertical surfaces without runs.
  • Easy application to complicated details.
  • Can be applied to a wide range of substrates with the appropriate primer.
  • Monolithic – no welds (no hot work or torches) or seams.
  • High water vapour permeability – low risk of blistering.
  • Excellent mechanical, chemical and crack bridging properties.
  • Resistant to standing water.
  • Thermoset – does not soften at high temperatures and remains elastic at low temperatures; Tg: 45°C (approximately).
  • No solvent.
  • CE marked.

Applications:

Used in a variety of waterproofing applications where a degree of chemical resistance is required. These include sewage effluent, and secondary containment bunds within the dirty water, chemical and petrochemical industries. Can be applied to the majority of substrates irrespective of falls. Spray delivered and ultra-fast cure enables easy application to form a monolithic waterproofing membrane on simple and complex surfaces.

General information
Finish

False

Color

black , grey , light grey

Features

Rapid setting, easy application to complicated details, no welds or seams, excellent mechanical and chemical resistance and crack bridging properties, resistant to standing water, solvent free

Uniclass 2015
Pr_35_31_68_47 Liquid tanking resinsPrimary
Specification data - Liquid tanking resins
Product Reference

MasterSeal M 689

ProductInformation

https://assets.master-builders-solutions.basf.com/Shared%20Documents/PDF/English%20(United%20Kingdom)/BASF-MasterSeal-M689-tds.pdf

Standard product features

Technical characteristics:

  • Working time: Three hours.
  • Fully cured: After two hours.
  • Application temperature (substrate and material): 5–35°C.
  • Adhesion to concrete: ≥ 1.5 N/mm².
  • Impact resistance: Class III.
  • Resistance to fire: Class Cfl-s1.
  • Water vapour permeability: Class I.
  • Tensile strength: 21 N/mm².
  • Elongation to break: 425%.
  • Capillary absorption and permeability to water: < 0.1 kg/(m²xh0.5).
  • Thermal compatibility after freeze-thaw cycling: ≥ 1.5 N/mm².

Digital objects
PlatformCompatibleVersionCertified to
Revit
Revit 2015 1 1.3
IFC
IFC2X3 1 1.3
Download now from NBS National BIM Library
