Barrier 80
Verified by manufacturer 23 days ago
QA Certificate
Certificate type
Two-component polyamide cured zinc-rich epoxy primer coating.
Application
Suitable for carbon steel, repair of inorganic zinc silicate coating and damaged galvanized steel substrates exposed to a wide range of corrosive atmospheric environments, up to very highly corrosive.
Recommended for offshore environments, refineries, power plants, bridges, buildings, mining equipment and general structural steel.
Description
A two-component polyamide cured epoxy coating designed as a primer for coating systems where extended durability is required.
The product conforms to the compositional requirements of SSPC paint 20, level 2 and ISO 12944-5 and complies with ASTM D520 type II zinc dust.
Features and benefits:
- A high-solids, zinc-rich epoxy coating.
- Quickly dries for recoating and handling.
- Designed for severely corrosive environments.
General information
Color | Grey |
Material | Epoxy resin |
Shape | Formless |
Uniclass | |
CAWS | G10/630 Galvanizing plus site-applied G10/635 Thermally sprayed zinc coating plus site-applied G10/638 Shop priming G10/640 Shop painting G10/65 Shop priming for G10/650 Site painting G10/660 Shop plus site painting M60/12 Gloss paint M60/130 Gloss paint M60/175 Protective coating M61/115 On-site coating to galvanized steel M61/120 On-site coating to existing steel M61/150 Off-site coating to unprimed steel M61/170 Off-site coating to galvanized steel |
Product range |
Specification data - Solvent-borne metal primers
Composition | Two component, polyamide-cured, zinc-rich epoxy coating. |
Capacity | 9 L. |
BIM objects
NBS BIM Object Standard
This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.
Find out more about the NBS BIM Object Standard.
| Platform | Compatible | Version |
|---|---|---|
 IFC | - | 1 |
 Revit | - | 1 |
Third party certifications
QA Certificate
International Organization for Standardization: ISO 12944-6 - C5-I
