Balcony Buildup on Cement Board - Liquid Applied Warm Roof System

Name: Balcony Buildup on Cement Board - Liquid Applied Warm Roof System
Brand: WestWood Liquid Technologies Limited
SKU: 7f1ySPVWxg44dbHVv3Y7L3

Verified by manufacturer 4 days ago

WestWood Liquid Technologies Limited

Third party certifications:

European Technical Approval (ETA)
Certificate type
BBA Agrément Certificate
Certificate type
EPD
Certificate type
KIWA BDA
Certificate type
FM Approved
Certificate type

A PMMA based balcony waterproofing system with PIR insulation and cement board.

Jump to:

BOS

+44 800 808 5480 Website

Application

For balconies.
Suitable for new build and refurbishment projects.

Description

A PMMA based balcony waterproofing system with PIR insulation and cement board. Particularly suitable for both new build and refurbishment projects. Hardwearing finish, available in a variety of colours - cold applied waterproofing.

System components:

Weplus SA bonding agent.
Weplus SA VB PL - Vapour barrier and preparation layer.
Weplus insulation/cement roof board adhesive.
PIR insulation.
Weplus insulation/cement roof board adhesive.
Weplus cement roof board.
Wecryl 176 - Resin primer.
Wecryl R 230 and Wecryl R 230 thix - Waterproofing resin.
Wecryl 333 - Self-levelling mortar.
Quartz sand 0.71–1.25 mm.
Wecryl 489 - Fire-retardant s1 finish, pigmented.

General information

Color	Grey Other
Finish	Anti-slip
Material	Polymethyl methacrylate (PMMA) Polyisocyanurate (PIR)
Shape	Other
Length	Bespoke
Width	Bespoke
Height	Bespoke
Warranty description	Ten year

Uniclass	Ss_30_40_30_43 Liquid-applied warm roof covering systemsPrimary
CAWS	J31/10 Warm deck roof coating J31/120 Warm deck roof coating

Specification data - Liquid-applied warm roof covering systems

System performance	Fire performance: Broof(t4) classification to EN 13501-5:2016. Guidance for specification option: Refer to the Warrington Fire classification report for details.
Preparation	-
Horizontal work	Weplus SA Bonding Agent. Guidance for specification option: One-component, solvent-based SBS adhesive primer. Used to aid adhesion of Weplus SA VB PL to concrete and various porous substrates.
Skirtings and vertical work	Weplus SA Bonding Agent.
Air and vapour control layer	Weplus SA VB PL. Guidance for specification option: A multi-layer self-adhesive vapour barrier and carrier membrane made of polymer-modified bitumen with a glass-fibre mat reinforcement and an aluminium foil as top layer. Can be applied over most common substrates such as concrete, plywood/OSB and metal decks.
Insulation	-
Type	PIR insulation. Guidance for specification option: Thickness to suit required U-value; consult manufacturer for details.
Fixing	Weplus insulation adhesive. Guidance for specification option: A single component polyurethane roofing adhesive, developed specifically for the bonding of rigid insulation boards to a variety of roof decks and vapour control layers.
Overlay	-
Type	Weplus cement roof board primed with Wecryl 176. Guidance for specification option: Weplus cement roof board: 12 mm thick board. Euro Class A1 - BS EN 13501-1 Class A1 non-combustible. Wecryl 176: Two-component, fast-reactive/ fast-curing PMMA-based (polymethyl methacrylate) resin primer. Available in white or clear (unpigmented).
Fixing	Weplus insulation adhesive.
Liquid-applied waterproofing	-
Type	Wecryl R 230 and Wecryl R 230 thix waterproofing resins. Guidance for specification option: Two-component, fast-curing and highly flexible. Wecryl R 230 thix is a variant of Wecryl 230 with improved non-sag/ thixotropic properties to reduce run-off when the waterproofing resin is applied to sloping and vertical surfaces. It is used primarily for the waterproofing of details. Available in RAL 7032 pebble grey and RAL 7043 traffic grey (Wecryl R 230 thix/Wecryl R 230 thix HT).
Reinforcement	Westwood reinforcement fleece.
Surface treatment	Wecryl 333 self-levelling mortar, quartz sand 0.71–1.25 mm, Wecryl 489 wearing layer. Guidance for specification option: Wecryl 333: Three-component, fast-reactive, flexibilised and filled PMMA-based self-levelling mortar. Serves as protection for the waterproofing layer. Available in RAL 7032 pebble grey and black. Quartz sand: Installed into the wet Wecryl 333. Wecryl 489: Two-component, fast-curing, pigmented PMMA-based (polymethyl methacrylate) sealing resin. Available in RAL 7030 stone grey, RAL 7032 pebble grey, RAL 7035 light grey, RAL 7043 traffic grey. More RAL colours upon request.
System completion	Installation to be signed off by WestWood Field Technician.

Sustainability data

Contains Red List materials	No
Country of material origin	Germany
Country of product manufacture	Germany
Material	Polymethyl methacrylate (PMMA) Polyisocyanurate (PIR)
