Application

ARDEX A 38 MIX Pre-Blended Rapid Drying Screed

for internal and external screeds is ideal for restricted areas where mixing equipment cannot be used.

Description

A special cement for producing a rapid setting, hardening and drying floor screed for internal or external use, including swimming pools, allowing ceramic tiles or stone to be fixed after only four hours, even on unbonded and floating screeds. It can be used to produce a bonded screed, an unbonded floor screed laid onto a membrane, or a floating floor screed laid onto a compressive quilt/ insulating material.


Features and benefits:

  • Rapid hardening – walkable in three hours.
  • Receives ceramic and natural stone tiles directly after only four hours for bonded, unbonded and floating screeds.
  • Install resilient, wood finishes and vinyl floor coverings after 48 hours.
  • After only one day the compressive and tensile bending strengths of ARDEX A 38 exceeds the acceptable minimum attained by an ordinary cement screed after 28 days.
  • Can be used with underfloor heating systems.
  • Can be pumped for fast application.
  • Compressive strength: After one day: 25.0 N/mm², After seven days: 40.0 N/mm², After 28 days: 45.0 N/mm².
  • Tensile bending strength: After one day: 4.0 N/mm², After seven days: 4.5 N/mm², After 28 days: 5.5 N/mm².


Thickness:

Should be applied at the following thicknesses for normal cement/ sand screeds:

  • Minimum 15 mm (design thickness up to 40 mm) for bonded screeds.
  • Minimum 40 mm for unbonded screeds.
  • Minimum 75 mm for floating screeds (65 mm in lightly loaded (domestic) locations).
  • When used for screed repair, it can be applied to the full thickness of the existing cement/ sand screed.

General information

Color

Grey

Finish

Smooth

Material

Cement

Shape

Formless

Length

Bespoke

Width

Bespoke

Height

-

Manufacturer guidance

Recommended thickness for type of screed needed:


Bonded: 15-40mm

Unbonded: 40mm+

Floating Domestic: 65mm+

Floating Commercial: 75mm+

Warranty description

Ten year

Uniclass

Pr_35_31_06_69 Quick-drying levelling screed mixesPrimary
Pr_35_31_06_77 Screed flooring

CAWS

M42/220 Concrete/ Screed substrates

M42/30 Concrete/ Screed substrates

M10/115 Cement:sand levelling screeds

M10/130 Proprietary quick drying levelling screeds

M10/110 Bonded cement:sand levelling screeds

M10/4 Cement:sand levelling screeds

Product range

Floor Screeds

Specification data - Quick-drying levelling screed mixes

Fine aggregate

Required.

Guidance for specification option:

Included.

Mix

Guidance for specification option:

Pre-mixed, no need to add aggregate

Manufacturer guidance

Pre-mixed, no need to add aggregate.

Drying time

3—48 hours.

Manufacturer guidance

  • 3 hours: Walkable.
  • 4 hours: Receives ceramic and natural stone tiles.
  • 48 hours: Install carpet, wood and vinyl floorcoverings.

Bonded

15 mm.

Unbonded

40 mm.

Floating floor

75 mm.

65 mm.

Guidance for specification option:

Lightly loaded/domestic locations.

Sustainability data

Country of product manufacture

United Kingdom

Recyclability

For disposal considerations see Health and Safety Datasheet at www.ardex.co.uk.

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit

Revit 2016

2

IFC
-

2
