AMF THERMATEX® Feinstratos Micro
Verified by manufacturer 5 months ago
Board
Board
Micro-perforated textured ceiling tiles with fire protection and acoustic properties. Board, Tegular 15, Tegular 24 and congealed edge details Finesse, SL2, K2 C2
Application
For use in retail, offices and meeting rooms, installation rooms or production areas.
Description
Micro-perforated textured tiles with fire protection and acoustic properties. Irregular holes provide increased sound absorption values, and the finely sanded surface gives the ceiling tile a distinctive, refined appearance.
Features and benefits:
- Fire protection and acoustics properties.
- Fine sanded surface.
- Increased sound absorption.
- Also available in 19 mm thickness.
General information
Color | White |
Finish | Guidance for specification option: Available with a special hygena antimicrobial treatment surface finish that prevents bacterial and fungal contamination of the tile. |
Material | Mineral fibre |
Shape | Square Rectangle |
Length | 600 mm 1200 mm 1500 mm 1800 mm 2000 mm |
Width | 300 mm 600 mm |
Height | 15 mm 19 mm |
Warranty description | Manufacturer guidanceIndividual Product and Approved KCS System Installed |
Uniclass | |
CAWS | K40/10 Unit/ modular suspended ceilings K40/105 Suspended ceiling system |
Specification data - Mineral fibre infill units
Third-party certification | Indoor Air Quality Class A+. |
Fire performance | |
Reaction to fire | To BS EN 13501-1, Euroclass A2-s1, d0. |
Unit type | Sand textured ceiling tile with micro perforations. Exposed Ventatec grid system.Guidance for specification option: Other sizes and edge details are available for special order. |
Material | Mineral fibre. |
Recycled content | 37–43%. |
Unit size | |
Face dimensions | 600 x 600 mm.625 x 625 mm.1200 x 600 mm.1250 x 625 mm. |
Thickness | 15 mm.19 mm. |
Surface texture | Sand textured. |
Colour | White. |
Edge profile | Square.Rebated. |
Light reflectance | 85%. |
Sound attenuation (15 mm thick tiles) | To BS EN 10848 and EN ISO 717-1, Dn,f,w = 34 dB. |
Weight | 3.9–5 kg/m². |
Constant humidity resistance | 95% RH. |
Sound absorption | To BS EN ISO 354, αw = 0.60 (Class C). |
19 mm thick tiles | To BS EN 10848 and EN ISO 717-1, Dn,f,w = 38 dB. |
Sound reduction | To EN ISO 10848-2 and EN ISO 717-1, Rw = 21 dB. |
System | Exposed demountable - System C. |
Sustainability data
Contains Red List materials | No |
Country of material origin | France |
Country of product manufacture | France |
Embodied carbonA1-A3 (production stage) as defined in BS EN 15804 | Manufacturer guidancePlease refer to EPD |
Recyclability | Manufacturer guidancePlease see EPD |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 43 % |
Literature
AMF THERMATEX® Feinstratos Micro
