Aluprof MB-SUNPROF - Standard Elliptical Blade System

Verified by manufacturer 6 months ago

Aluprof UK Third party certifications:
  • Cradle to Cradle Certified

    Cradle to Cradle Certified

    Certificate type

  • ISO 14001 Environmental Management Systems

    Certificate type

  • ISO 9001 Quality Management

    Certificate type

  • Qualicoat approval

    Qualicoat approval

    Certificate type

Aluminium brise soleil system.

Jump to:
+44 (0)161 9414005 Website

Application

  • New build
  • Refurbishment
  • Low-rise buildings
  • High-rise buildings
  • Commercial
  • Hospitality
  • Leisure
  • Public sector
  • Industrial
  • Residential
  • Retail

Description

Brise soleil system with aluminium blades, which are available in a variety of sizes and integrate with Aluprof’s curtain wall systems range.


Features and benefits:

  • Incorporates solar glare control with the appropriate amount of natural light coming into the building’s internal environment.
  • A range of outriggers (brackets) available.
  • A selection of aluminium blade profiles is available, width: 100–300 mm, to meet project requirements.
  • 45° (maximum) angle available on the blades.
  • Quick and easy to install on the curtain wall, loadbearing wall or window frame.

General information

Finish

Anodized

Powder-coated

Material

Aluminium

Shape

Other

Length

Bespoke

Width

Bespoke

Height

Bespoke

Warranty description

25 year

Guidance for specification option:

Maximum warranty for polyester powder-coating finish. Consult manufacturer for details of marine and industrial environments.

Ten year

Guidance for specification option:

Anodized finish.

Uniclass

Ss_25_50_75_65 Projecting brise soleil systemsPrimary

CAWS

L10/55 Brises-soleil

L10/670 Brises-soleil

Specification data - Projecting brise soleil systems

Shading device

-

Type

Aluminium brise-soleil louvre blades.

Guidance for specification option:

Specify blade width/ angle below.

System accessories

None.

Outrigger (bracket), 85 x 50 mm.

Outrigger (bracket), 95 x 50 mm.

Outrigger (bracket), 100 x 50 mm.

System completion

The MB-SUNPROF solar shading system specified above shall be fabricated and installed by Aluprof approved companies only, in complete accordance with the information and guidance distributed by Aluprof UK Ltd.

Blade width

Elliptical, 100 mm.

Guidance for specification option:

Depth: 20 mm.

Elliptical, 150 mm.

Guidance for specification option:

Depth: 28 mm.

Elliptical, 200 mm.

Guidance for specification option:

Depth: 36 mm.

Elliptical, 250 mm.

Guidance for specification option:

Depth: 44 mm.

Elliptical, 300 mm.

Guidance for specification option:

Depth: 52 mm.

Blade angle

Projection

Projection: 101.5 mm.

Sustainability data

Contains Red List materials

No

Country of product manufacture

United Kingdom

Recyclability

Cradle to Cradle

Recycled content

As defined in clause 7.8 of BS EN ISO 14021

59.57 %

Third party certifications

Third party certifications

Cradle to Cradle Certified

Cradle to Cradle Certified

Cradle to Cradle Certified™ - Bronze

ISO 14001 Environmental Management Systems

ISO 14001 Environmental Management Systems

Aluprof ISO 14001 Certificate

ISO 9001 Quality Management

ISO 9001 Quality Management

Aluprof ISO 9001 Certificate

Qualicoat approval

Qualicoat approval

Aluprof Qualicoat Certificate 2022
