Aluprof MB-118EI - Fire Resistant Glazing System
Verified by manufacturer 7 months ago
Aluprof MB-118 EI120 - External shopfront system - 120 minute integrity and insulation rated
Aluprof MB-118 EI120 - External shopfront system - 120 minute integrity and insulation rated
EPD
Certificate type
ISO 9001 Quality Management
Certificate type
Qualicoat approval
Certificate type
Up to EI120 (integrity & Insulation) fire rated aluminium screenwork system
Application
- New build projects
- Refurbishment projects
- All building types: residential, commercial, public buildings etc
- Fire-rated internal partitions
- Fire rated windows
- Fire rated shop fronts
- Fire rated glazed screenwork
Description
Fire-rated EI120 aluminium fixed screens, to EN 13501-2.
Features and benefits:
- Internal and external glazed windows and wall partitions with a height up to 4.0m.
- Ability to combine a large number of units in the width, offering flexibility and variety of use.
- The MB-118EI system can accommodate single, double or triple glazed infills with a thickness of 31-84 mm
- Compatible with Aluprof MB-78EI door systems.
Performance:
- Air permeability to EN 12152:2004: Class A4.
- Watertightness to EN 12154:2004: Class RE750.
- Fire resistance to EN 13501-2: EI 120
General information
Finish | Anodized Powder-coated |
Material | Aluminium Glass |
Shape | Square Rectangle |
Length | Bespoke |
Width | Bespoke |
Height | Bespoke |
Uniclass | |
CAWS | L10/56 Glazed screen system L10/550 Glazed metal screens |
Specification data - Panel partition systems
Panel partitioning | Partition panels. |
Fasteners | Manufacturer guidanceConsult manufacturer for options and insert requirements. |
Joint treatment | Manufacturer guidanceConsult manufacturer for options and insert requirements. |
Joint finish | Manufacturer guidanceConsult manufacturer for options and insert requirements. |
System accessories | Manufacturer guidanceConsult manufacturer for options and insert requirements. |
System completion | The MB-118 EI fire-rated system specified above shall be fabricated and installed by Aluprof approved companies only, in complete accordance with the information and guidance distributed by Aluprof UK Ltd. |
Screen height | Guidance for specification option: Consult manufacturer for options and insert requirements. Tested to 4.0 m. |
Fire resistance rating of complete system | EI120. Guidance for specification option: To EN 13501-2. |
Sound insulation rating | Guidance for specification option: Consult manufacturer for options and insert requirements. |
Thermal performance | Guidance for specification option: Consult manufacturer for options and insert requirements. |
Glazing details | Guidance for specification option: Thickness: 31–84 mm available. Consult manufacturer for details and insert requirements. |
Incorporated features | Guidance for specification option: Consult manufacturer for options and insert requirements. |
Sustainability data
Contains Red List materials | No |
Country of product manufacture | United Kingdom |
Recyclability | Cradle to Cradle |
Third party certifications
Third party certifications
EPD
Aluprof Environmental Product Declaration to EN 15804 - Window & Door Systems
ISO 9001 Quality Management
Aluprof ISO 9001 Certificate
Qualicoat approval
Aluprof Qualicoat Certificate 2022
Literature
MB-118 EI fire rated glazing system - Product Information
Aluprof Systems Overview
Architectural Product Guide
Company Brochure
Cradle to Cradle Certified™ Bronze
Fenestration that offers fire and smoke protection
Fire Rated & Smoke Exhaust Glazed Systems
