AEG SATELLITECLEAN DISHWASHER 45CM - FSB73427Z

Verified by manufacturer 6 days ago

Electrolux Group

Integrated dishwasher.

Jump to:
BOS
+447932836387 Website

Application

For domestic use.

Description

Integrated dishwasher. Responsible choices made easy. Use the QuickSelect touchscreen slider to select your preferred cycle time and the Ecometer guides you to the most sustainable program to save energy and water through visually green bars.

With SatelliteClean®. The innovative spray arm guarantees corner-to-corner cleaning. With up to 3x better spray coverage providing stunning results across every surface.

Features and benefits:

  • Capacity: nine place settings.
  • Seven programmes, three temperatures.
  • Dishwasher programmes: 160 minutes, 60 minutes, 90 minutes, AUTO Sense, Eco, Machine Care, Quick 30 minutes.
  • ProClean Satellite Spray arm.
  • Text/ symbol panel.
  • Touch control for programs and functions selection.
  • Auto Off function
  • Thermo Efficient Technology.
  • Warm water connection up to 60°C.
  • Delay start option from 1 to 24 hours.
  • Remaining time indication.
  • Water sensor detects the level of dirt and adjusts water consumption.
  • Indications for salt and rinse aid.
  • SpotControl with two colours.
  • Height adjustable upper basket, even when fully loaded.
  • Upper basket with six wine glass soft grips, two soft spikes, foldable cup shelves, plastic handle.
  • Lower basket with two foldable tines, plastic handle.
  • Cutlery basket.
  • AQUA-CONTROL.

General information

Color

White

Shape

Rectangle

Length

550 mm

Guidance for specification option:

Depth

Width

450 mm

Height

900 mm

Guidance for specification option:

Maximum. Adjustable 820–900 mm.

Warranty description

Two year

Uniclass

Pr_40_70_21_24 Domestic dishwashersPrimary

CAWS

N12/400 Dishwashing machines

N12/400 Dishwashing machines

Specification data - Domestic dishwashers

Description

Integrated dishwasher.

Manufacturer

Electrolux Group.

Installation

Integrated.

Arrangement

Nine place settings.

Material and finish

White-coated steel.

Dimensions

-

Height (maximum)

900 mm (adjustable 820–900 mm).

Width (maximum)

446 mm.

Depth (maximum)

550 mm.

Rating

1.95 kW.

Electrical supply

220–240 V, 50 Hz.

Water connections

Cold or hot.

Environmental rating

E.

Water consumption (maximum)

9.9 L.

Drying performance

-

Manufacturer guidance

AirDry delivers up to 3x better drying performance when compared to closed-door systems.

Noise level at 1 m (maximum)

46 dB.

Programmes

-

Number (minimum)

Seven.

Guidance for specification option:

160 minutes, 60 minutes, 90 minutes, AUTO sense, ECO, machine care, quick 30 minutes.

Features

Beam on floor two coloured, buzzer, Delay start 1–24 hour, drying phase, GlassCare, machine care, program selected, rinse aid, salt, XtraPower.

Special features

SatelliteClean®, QuickSelect touchscreen slider.

Guidance for specification option:

QuickSelect touchscreen slider to select your preferred cycle time and the Ecometer guides you to the most sustainable program to save energy and water through visually green bars.

Water supply

Hot or cold.

HoseLength

150 mm (inlet), 150 mm (outlet).

Sustainability data

Country of product manufacture

Europe

Manufacturing plant location

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1
