AEG ECOLINE HOB2HOOD CANOPY COOKER HOOD 54CM - DGE5661HM - Canopy Hood

Verified by manufacturer 16 days ago

Electrolux Group

Automatically controlled extractor.

Jump to:
BOS
+447932836387 Website

Application

For domestic use.

Description

The​ 6000 Hob2Hood automatically controls the extraction speed and light, creating a fresh cooking atmosphere. Regardless of what you're cooking, the hood adjusts the fan speed to get rid of steam and odours.


Features and benefits:

  • ​ Electronic variable 3+Intensive speed push button control.
  • Washable aluminium grease filters.
  • Extraction mode.
  • For installation into an island chimney or corner unit.

General information

Color

Silver

Material

Stainless steel

Shape

Rectangle

Length

300 mm

Guidance for specification option:

Depth

Width

540 mm

Height

331 mm

Warranty description

Two year

Uniclass

Pr_60_65_94_46 Kitchen extractor hoodsPrimary

CAWS

N11/360 Appliances

N11/40 Appliances

Specification data - Kitchen extractor hoods

Operation

Extraction.

Installation

Integrated into wall unit.

Material and finish

Brushed stainless steel.

Dimensions

-

Width (maximum)

540 mm.

Depth (maximum)

300 mm.

Height

331 mm.

Capacity (minimum)

435 m³/h.

Guidance for specification option:

Minimum recirculated extraction rate, 295 m³/h.

Maximum recirculated extraction rate, 430 m³/h.

Intensive recirculated extraction rate, 435 m³/h.

Controls

Electronic three-speed.

Features

Aluminium removable grease filter.

Electrical supply

220–240 V, 50 Hz.

Noise level at 1 m (maximum)

54–67 dB.

Guidance for specification option:

Minimum recirculated noise level, 62 dB.

Maximum recirculated noise level, 75 dB.

Sustainability data

Country of product manufacture

Europe

Material

Stainless steel

Manufacturing plant location

BIM objects

BOS

NBS BIM Object Standard

This BIM object has been authored to meet the requirements of the NBS BIM Object Standard.

Find out more about the NBS BIM Object Standard.

Platform Compatible Version
Revit
-

1

IFC
-

1

Literature

DGE5661HM - Data Sheet

DGE5661HM - Data Sheet

DGE5661HM - User Manual

DGE5661HM - User Manual

EnergyLabel_942022577

EnergyLabel_942022577

DGE5661HM - Product Information Sheet

DGE5661HM - Product Information Sheet
