Adjustable height and sideways MATRIX powered basin unit R482719000
Verified by manufacturer 4 days ago
MATRIX MEDIUM Wash basin bracket, with white installation cover, incl. feed & waste system & shallow trap. Electrically height adjustable 300 mm with operating buttons. Required MATRIX MEDIUM R2122
Application
Intended for optimum ergonomics at a wash basin, for both seated and standing users with disabilities. Ideal for Changing Places and accessible bathrooms.
Can only be used with MATRIX MEDIUM wash basins R2122 and R2123.
Description
MATRIX MEDIUM Wash basin bracket, wall-mounted, with white installation cover, including feed and waste system and shallow trap (R2058).
Features and benefits:
- Electrically height adjustable 300 mm with operating buttons (in front edge of wash basin), and manually sideways adjustable 500 mm.
- Concealed plumbing cover - hygienic.
- WRAS approved.
- Five year guarantee.
Required (but not included) items:
- R2122 MATRIX MEDIUM wash basin with overflow and two integrated handrails in the front or R2123 MATRIX MEDIUM wash basin without overflow.
- Drain fitting LA1319 chain and plug.
- Tap
General information
Color | White |
Finish | Powder-coated |
Material | Steel Polystyrene Polymethyl methacrylate (PMMA) Acrylonitrile butadiene styrene (ABS) |
Shape | Other |
Length | 910 mm |
Width | 802 mm |
Height | Bespoke Manufacturer guidanceHeight adjustable between 610–910 mm. |
Warranty description | Five year |
Uniclass | |
CAWS | N13/335 Washbasins N13/30 Washbasins |
Specification data - Washbasin support brackets
Form | Wall-mounted bearers. |
Materials | |
Bearers | |
Body | Steel. |
Finish and colour | White. |
Drain | LA1319 chain and plug. |
Integral accessories | Fixing bolts for washbasin. |
Load | 150 kg (maximum). |
Operation | Operating buttons. |
Power consumption | 66 W (maximum load). Guidance for specification option: Power consumption (standby) 0.5 W. |
Noise | 50 dB. |
Operating voltage | 230 V. |
Frequency | 50/ 60 Hz. |
Weight | 24.8 kg. |
Height | 610–910 mm. |
Colour | White. |
Wash basin | R2122. Guidance for specification option: MATRIX MEDIUM wash basin with overflow and two integrated handrails in the front. R2123. Guidance for specification option: MATRIX MEDIUM wash basin without overflow. Manufacturer guidanceTo be specified separately. |
Sustainability data
Contains Red List materials | No |
Country of material origin | Denmark |
Country of product manufacture | Denmark |
Material | Steel Polystyrene Polymethyl methacrylate (PMMA) Acrylonitrile butadiene styrene (ABS) |
BIM objects
| Platform | Compatible | Version |
|---|---|---|
 Revit | - | 1 |
Literature
MATRIX powered basin unit, height and sideways adjustable
MATRIX manual basin unit, height and sideways adjustable
CPD materials
Best Practice in Accessible Bathroom Design (2023).
