ADAGIO Acoustic+ - Demountable Ceiling Tile Systems
Verified by manufacturer 1 day ago
ADAGIO Acoustic+, Board infills
ADAGIO Acoustic+, Board infills
Demountable ceiling tile systems with a smooth, uniform, and durable surface with unparalleled scratch resistance and the brightest white visual available.
Application
Suitable for use in a variety of ceiling areas, including:
- Acoustic+: meeting rooms or waiting areas.
- Acoustic+ planks: both open areas and corridors.
Description
ADAGIO Acoustic+
offers a smooth, uniform, and durable surface with
unparalleled scratch resistance and the brightest white visual available.
Thanks to its exceptional air permeability (no filter effect), the surface
remains whiter and brighter for an extended duration. The tile also provides
a balance of both sound absorption and sound attenuation, as well as
high light reflectance.
■ Good sound absorption and high sound attenuation:
0.65 αw and 39 dB (Board, Tegular 24/90, Tegular 15/90, SL2, SL2 /
Tegular 15/90, Finesse) or 38 dB (Vector).
■ Excellent light reflectance: 88%.
■ ISO 4, Indoor Air Comfort Gold and Cradle to Cradle Certified® Bronze.
■ ADAGIO Acoustic+
: ideal for meeting rooms or waiting areas.
ADAGIO Acoustic+
Planks: ideal for both open areas and corridors
General information
Color | White Guidance for specification option: RAL 9010. |
Finish | Painted Guidance for specification option: Post-coated. |
Material | Mineral wool |
Shape | Square Guidance for specification option: Infills units or overall system. Rectangle |
Length | 600 mm 1200 mm 1250 mm 1500 mm 1800 mm Manufacturer guidanceInfill unit dimensions only. |
Width | 300 mm 600 mm Manufacturer guidanceInfill unit dimensions only. |
Height | Bespoke |
Warranty description | Manufacturer guidanceIndividual product and approved KCS system installed |
Uniclass | |
CAWS | K40/10 Unit/ modular suspended ceilings K40/115 Unit/ modular suspended ceiling system K40/105 Suspended ceiling system |
Specification data - Modular suspended ceiling systems
System performance | Guidance for specification option: Insert requirements. |
Ceiling support | Exposed demountable - System C. |
Support fasteners | Manufacturer's standard. |
Ceiling units | Lay-in board infill, 600 x 600 mm. Lay-in board infill, 625 x 625 mm. Lay-in board infill, 675 x 675 mm. Lay-in board infill, 1200 x 300 mm. Lay-in board infill, 1200 x 600 mm. Lay-in board infill, 1250 x 625 mm. Lay-in board infill, 1500 x 600 mm. Lay-in board infill, 1800 x 600 mm. |
Samples required | Product samples Demountable suspended ceiling prototypes Not required |
Weight | 5.0–8.6 kg/m². |
Light reflectance | 88%. |
Constant humidity resistance | 95% RH. |
Third-party certification | Indoor Air Quality Class A+. |
Reaction to fire | To EN 13501, Euroclass A2-s1, d0. |
Colour | White. Manufacturer guidanceInfill units only. |
Cleanroom classification | To EN ISO 14644-1, ISO 4. |
Sound absorption | To EN ISO 354 αw = 0.65 as per EN ISO 11654 - Class C. |
Sound attenuation | To EN ISO 10848-2. |
Sound reduction | To EN ISO 10140-2, Rw = 22 dB. |
Thickness | Infill units: 19 mm. |
Sustainability data
Contains Red List materials | No Manufacturer guidanceplease refer to EPD |
Country of material origin | United Kingdom |
Country of product manufacture | United Kingdom |
Material | Mineral wool |
Recyclability | Manufacturer guidancePlease see EPD |
Recycled contentAs defined in clause 7.8 of BS EN ISO 14021 | 14 % |
Literature
ADAGIO Acoustic+ datasheet
