ACO UniFace™ GS ASSIST
Compare variants

ACO UniFace™ GS ASSIST

ACO Technologies plc Variant:

Designed to blend with hard and flexible floors.

Jump to:
+44 (0)1462 816666 www.aco.co.uk

Application

Designed for internal and external applications associated with commercial, private and public sector buildings, including:


  • Shopping centres.
  • Transport hubs.
  • Leisure facilities.
  • Residential.
  • Hospitals.
  • Education.
  • Warehousing.
  • Kitchens.
  • Landscaping.

Description

Hot dipped galvanised steel gas spring assisted single recessed covers, designed for one person minimal effort operation. Ideal in areas where frequent access is required. With a frame depth of 89 mm, these hinged covers are ideal for pedestrian, light vehicle and medium duty fork-lift truck areas. Wide range of size options available for clear openings of between 400 mm and 1000 mm. FACTA class B, C and D.


Features and benefits:


  • Provides a high quality finish.
  • Easy access to underlying services and ducting.
  • Manufactured using recycled materials.
  • Gas spring assist for minimal effort, one-person operation.
  • Self-locking safety stay.
  • Hinge blocks unbolt, allowing cover to be completely removed for unimpeded access.
  • Suitable for areas where frequent access is required.
  • Stainless steel locking bolts provided to ensure safety.
  • High performance, liquid and odour-tight EPDM seals included.
  • Wide range of sizes available for clear openings of 400–1000 mm.
  • Can be used on a variety of floor finishes, including concrete, epoxy surfaces, terrazzo, ceramic tiles, carpets and wood.
  • Suitable for floor finishes of up to 15 mm thickness.
  • Manufactured and classified according to the FACTA specification.

General information

Color

Silver

Finish

Polished

Material

Steel

Shape

Rectangle

Size

1142 x 1175 mm

1142 x 975 mm

1142 x 775 mm

1042 x 1075 mm

1042 x 775 mm

Show more

Uniclass 2015

Pr_65_52_01_02 Access covers, gratings and framesPrimary

CAWS

P30/301 Access covers/ manhole tops and frames

Specification data - Access covers, gratings and frames Enhanced data

Standards

Fabricated Access Cover Trade Association (FACTA) Specification.

Finish

Polished.

Clear opening (minimum)

800 x 800 mm.

Load class (minimum)

FACTA B.

Frame or support

Supplied with frame.

Integral accessories

400528 ACO UniFace™ GS/SS ASSIST Access Cover Lifting/Locking Key Set (2 x keys).

417449 ACO UniFace™ GS/SS ASSIST Access Cover Locking Screw Set (2 x screws and caps).

FrameDepth

89 mm.

Grade

304.

Stainless steel locking screws.

FrameSize

942 x 975 mm.

Environmental information

Recyclability

100%

Recycled content

60%
