54 mm deep aluminium thermally broken tilt/ turn window.
Suites with AA®541 Casement, AA®542 Pivot, AA®545 Swing Door, AA®100/ AA®110 Curtain Walling, 451PT Framing System and Door Systems.
The AA®543 Tilt/ Turn Window is part of the AA®540 Series window range, designed to offer optimum weather and thermal performance. It corresponds to the BRE Global Green Guide online generic specification for windows and achieves a summary rating of A+ for non-domestic schemes. The AA®543 uses a multi-chamber thermal break core, ensuring thermal efficiency and full compliance with Building Regulations (E&W) Approved Document L. The product is available as either a tilt/ turn only or a side-hung or bottom-hung window; the polyamide thermal break offers single or dual colour options.
Features and benefits:
ColorInsert requirements. | - |
Finish | Anodized Powder-coated |
Material | Aluminium |
SizeInsert requirements. | - |
Uniclass | |
CAWS | L10/25 Aluminium windows L10/330 Aluminium windows |
Dimensions and configurations | Horizontal pivot.Vertical pivot (central).Vertical pivot (offset). |
Product performance | - |
Weather performance | - |
Air permeability | To BS EN 12207, Class 4. |
Watertightness | To BS EN 12208, Class 9A. |
Resistance to wind load | To BS EN 12210, Class AE2400. |
Safety | - |
Security level | Not required.To Secured by Design standard.Standard security.To PAS 24.The product has been independently tested to PAS 24. Does not refer to standard hardware; security hardware required. |
Frame | - |
Finish as delivered | - |
Coating | Permacover polyester powder coated.Permanodic anodized. |
ColourInsert requirements. | - |
VentilatorTrickle vent. | Not required.Required. |
Execution | Fixing of aluminium frames. |
Pivot | Non-restricted. Restricted. |
Restrictor | Not required. Required. |
Thickness | 39 mm maximum infill. |
